Brivo ACS-SDC-E Installation Manual
Conguration Procedures
If any manual conguration is required, connect a laptop to the same local area network as the ACS-SDC-E unit
NOTE: The laptop and ACS-SDC-E unit MUST be on the same subnet.
1. Set your NIC interface on your laptop/PC to IP 169.254.242.122 and net mask 255.255.255.0 .
2. Connect the CAT5 or greater cable from the NIC interface on the laptop to the PoE network switch.
3. Connect another CAT5 or greater cable from PoE network switch to ACS-SDC-E unit. Allow a few
seconds for the ACS-SDC-E unit to boot up.
4. Open a web browser and navigate to 169.254.242.121 .
5. When the prompt appears for username/password, use username cli and password new5cli.
a) The Administrative Interface (WebCLI) is used to gain access to the onboard functionality for
debugging and manual conguration utilities.
Verify connection of the LAN to the ACS-SDC-E
1. Using CAT5 or greater cable, connect the LAN to the ACS-SDC-E unit via its LAN port.
a) The LAN port is a 10/100 Ethernet interface with an RJ45 jack for connecting the Ethernet
port on the ACS-SDC-E to a Local Area Network in order for it to gain connectivity to the
Internet.
b) Use a straight, (i.e., non-crossover) cable to connect this port to a local hub, switch or router.
2. Verify the connection of the LAN to the ACS-SDC-E by accessing the Administrative Interface
(WebCLI) Using the instructions listed in the previous step. On the main page of the Administrative
Interface, you should see a recent time/date stamp in the Last Contact with Central eld.
NOTE: Firmware Upgrade - When rst registered and connected to the Brivo cloud service, your ACS-SDC-E
will automatically download and install the latest rmware. This process may take several minutes, so do
not disconnect or cut power to your ACS-SDC-E during this process. If you encounter any diculties during
this process, please contact Brivo Technical Support at 866-274-8648 or email customercare@brivo.com.
Revision Table
Version Date Content
1.0 02/07/2023 Original document
1.1 02/17/2023 Updated wire requirements table
1.2 02/28/2023 Added wiring graphics
