Brivo ACS-SDC-E Installation Manual
Wire Requirements
Signal
Belden # or
Equivalent
AWG
Twisted
Pair
Shielded? Conductors Max Length
Power (18 gauge) 6300FE 18 No No 2 500 ft
RJ45-Ethernet N/A
Cat5 or
greater
Yes No 8 328 ft
Request-to-Exit 5520FE/6300FE 22/18 No No 4 500 ft
Door Contact 5500FE 22 No No 2 500 ft
Earth Ground N/A 18 No Yes 1 (solid) 40 ft
Reader OSDP 9842 24 Yes Yes 4 500 ft
Additional Resources
The following additional resources are available for the installer as well as the client.
· ACS-SDC-E Data Sheet
· Panel Networking Guide
· Brivo ACS-SDC-E Quick Start Guide
· Technical Support: 1-866-BRIVO-4-U
· www.brivo.com
· support.brivo.com (for non-hardware specic help)
