Broan ERV100HC - About this Manual

3
Table of Contents (cont’d)
About this Manual
8.0 INSTALLATION OF THE CONTROLS ..................................................24
8.1 Dimensions and Specifications ................................................24
8.2 Installation of the Main Control ..........................................24-25
8.3 Electrical Connection to Optional Controls ..............................26
8.4 Electrical Connection to the Furnace ......................................26
9.0 WIRING DIAGRAMS ....................................................................27-28
10.0 AIR F
LOW B
ALANCING................................................................29-30
11.0 OVERALL VERIFICATION ..................................................................31
11.1 Main Controls ..........................................................................31
11.2 Optional Control ......................................................................32
12.0 MAINTENANCE / INSTRUCTIONS FOR USER....................................33
13.0 TROUBLESHOOTING ....................................................................34-35
14.0 REFERENCES ....................................................................................36
This manual uses the following symbols to emphasize particular information:
NOTE: Indicates supplementary information needed to fully complete an instruction.
CAUTION
Denotes an instruction which, if not followed, may severely damage the unit and/or
its components.
WARNING
010
!
Identifies an instruction which, if not followed, might cause serious personal injuries including
possibility of death.
