Brodie BiRotor Plus - Page 22

Page 22/26IOM Single Case BiRotor Plus R06
Item Model Number Description Quantity
1 151098-419 Screw 1
2 151881 Waher 1
3 56033 Lock Button 1
4 56031-043 Pulse Wheel 1
5 151098-419 Screw 8
6 154046 Dowel Pin 4
7 56825-050 End Plate 2
8*
1500937-001 Bearings, Stainless Steel
4
1500937-001CER Bearings, Ceramic
9* 152066-( ) See note 2 O-Ring 4
10 56276-000 LH Rotor 1
11 56286-000 RH Rotor 1
12* 157361-( ) See note 2 O-Ring 2
17
56211-050M Measuring Unit Housing, MTR’s
1
56211-050N Measuring Unit Housing, MTR’s and NACE
18 56291 LH Timing Gear See note 1
19 56296 RH Timing Gear See note 1
20 1500942 Stop Nut 2
21
56819-100M Outlet Housing, 150# ANSI, MTR’s
1
56819-100N Outlet Housing, 150# ANSI, MTR’s and NACE
56819-040M Outlet Housing, DIN PN 16 and PN 40, MTR’s
56819040N Outlet Housing, DIN PN 16 and PN 40, MTR’s and NACE
56819-300M Outlet Housing, 300# ANSI, MTR’s
56819-300N Outlet Housing, 300# ANSI, MTR’s and NACE
22*
151555-419M Hex Nut, MTR’s
8
151555-419N Hex Nut, MTR’s and NACE
23*
1500941M Stud, MTR’s
4
1500941N Stud, MTR’s and NACE
26
56818-100M Inlet Housing,150# ANSI, MTR’s
1
56818-100N Inlet Housing,150# ANSI, MTR’s and NACE
56818-040M Inlet Housing, DIN PN 16 and PN 40, MTR’s
56818-040N Inlet Housing, DIN PN 16 and PN 40, MTR’s and NACE
58818-300M Inlet Housing,300# ANSI, MTR’s
58818-300N Inlet Housing,300# ANSI, MTR’s and NACE
27* 1500093-026 Weather Seal 1
28*
899-00-201-00 Pick Off, Standard
1
899-00-201-01 Pick Off, High Temp
Table 11-1 Parts List Single Case BiRotor Plus
