Page 23/26IOM Single Case BiRotor Plus R06
Item Model Number Description Quantity
29 1500418 Spring 1
30 86030-001 Hold Down 1
32* 151496M Umb Screws 9
36 CC-219Z-633-EBG Umb Cover 1
37*
230-00-300-00 Pre Amp Board
1
230-10-300-50 Terminal Board
39 CA-375Z-259-XXA Umb Gasket 1
41 899-00-100-00 Umb Housing 1
42* 1500909D Approved Stopping Plug 1
43 SD442 Plastic Cap Plug 1
Table 11-1 Parts List Single Case BiRotor Plus Continues
Notes:
*Items marked with a * are recommended spare parts.
1. These items are only available as a matched set, part number W56296.
2. O-ring material suffi x is as follows:
-022 : Viton A
-026 : Viton F
-016 : FluoroSilicon
3. When ordering the following information must be provided: Part number, Model Number, Serial
Number, and Quantity Required. This information is necessary for items marked C/F (Consult Factory).
