26
The inserts model Damasco and Neva have a level sensor (capacitive) inside the hopper that warns of the need
to refuel. This message does not stop the operation of the equipment but you have a few minutes to refuel before
the insert goes into the alarm state (alarm-6 “no pellet”) and stops its operation. In the remote control you will
read the following message:
4 SAFETY DEVICES
• SMOKE EXTRACTOR BREAKDOWN
If the extractor stops, the electronic card automatically blocks the fuel supply.
• BREAKDOWN OF THE FUEL LOADING MOTOR
If the geared motor stops, the stove or insert keeps on working (only the smoke extractor) until the minimum
working smoke temperature goes down and stops.
• TEMPORAL POWER LOSS
After a short power loss, the equipment will restart automatically. However in the event of a lack of electricity the stove may
give off a small amount of smoke inside the room for a period of approximately 3-5 minutes. THIS DOES NOT ENTAIL ANY
HEALTH RISK. This is a reason why Bronpi advises, whenever possible, to connect the primary air inlet pipe to the exterior
of the house in order to assure that the stove does not give off smokes after a short power loss.In the model Neva it is not
possible to connect the air intake duct with the outside because of the air intake comes directly from
the front of the insert.
• ELECTRICAL PROTECTION
The stove is protected against abrupt electricity oscillations through a general fuse placed in the back part.
(4A250V Retarded) (See drawing D3).
• SMOKE OUTLET PROTECTION
The electronic pressure switch blocks the operation of the stove in the event
of an abrupt change of the pressure inside the combustion chamber (door opening, breakdown of the
smoke extraction motor, smoke returns, etc). If this happens, the stove will go into an alarm state (see
drawing D4).
• PROTECTION IN THE EVENT OF HIGH TEMPERATURE OF PELLET (80ºC)
In the event of overheating of the internal part of the tank, this device blocks the operation of the machine. The
restart needs to be done manually by an authorised technician (see drawing D5).
The restoration of the 80ºC safety device is not included in the warranty unless the technical assistance centre can
demonstrate a faulty component.
• FLOW SENSOR (OASYS TECHNOLOGY).
Your stove or insert has a flow sensor (see drawing D6) placed inside the primary air suction pipe that detects the
proper circulation of combustion air and the smoke exhaust. In case of insufficient air inlet (due to incorrect smoke
outlet or improper air intake), the sensor sends a “block” signal to the stove.
The OASYS TECHNOLOGY (Optimum Air System) allows a constant combustion by controlling automatically the draft according to the
characteristics of the flue (curves, length, diameter, etc) and the environmental conditions (wind, humidity, atmospheric pressure, etc). To that
end, the fitter must enter in the technical menu the geographical altitude of the equipment installation place.
5 INSTALLATION REQUIREMENTS
The way of installing the stove or insert will affect the safety and the proper operation. For this reason, it is recommendable that the installation
is carried out by people who are qualified and informed about the compliance with the installation and safety norms.
If your equipment is not properly installed, it may cause serious damage.
Before the installation, follow the next verifications:
• Make sure that the floor can sustain the weight of the equipment and make a proper isolation in the case that it is made of flammable
material (wood) or a material that can be affected by a thermal shock (plaster cast, for example).
• If the equipment is installed on a floor which is not completely refractory or inflammable such as parquet, carpet, etc, it is necessary to
replace this part or introduce a fire-resistant base so that it protrudes out the oven 30 cm. Example of materials include steel flooring,
glass base or any other type of fire-resistant material.
D1
D4
D5
D6
D3
FUSE
MENU
D2
EMPTY
HOPPER
INSTALLATION, OPERATING AND SERVICING INSTRUCTIONS RADIOFREQUENCY SERIES
