Bronpi Olivia Extra - Installation Safety Measures; General Safety Measures

27
• Make sure that there is proper ventilation in the place where it is installed (air intake).
• Avoid the installation in places where there are collective ventilation pipes, hoods with or without extractor, B type gas equipments,
heat pumps or equipments that can cause that the draw is not good if they are used at the same time.
• Make sure that the smoke duct and the pipes used for the chimney are suitable for the operation of the insert.
• Make sure that every equipment has their own smoke duct. Do not use the same duct for several equipments.
We recommend that you call your fitter in order to check both the chimney as well as the air flow for the combustion.
5.1 SAFETY MEASURES
During the installation of the equipment, there are risks to be taken into account, so you should follow the next safety measures:
a. Keep any flammable or heat sensitive materials (furniture, curtains,
and clothing) at a minimum distance of about 150cm.
b. If the equipment is installed on a floor which is not completely
refractory or inflammable it is necessary to replace this part or
introduce a fire-resistant base.
c. Do not place the stove near combustible walls or likely to be
affected by a thermal shock.
d. The stove should only be used when the ash pan is inserted and the
door closed.
e. It is recommended to install carbon monoxide detector (CO) in the
room where the equipment is installed.
f. If you need a longer wire than the provided use it always with an
earthed plug.
g. Do not install the stove in a bedroom.
h. The appliance should never be turned on in the presence of
emission of gases or vapours (e.g., linoleum glue, gasoline, etc). Do
not place nearby flammable materials.
i. Solid combustion residues (ashes) should be collected in an airtight
container and resistant to fire.
j. It is necessary to keep a safe distance when they are installed in
spaces where materials are susceptible of being flammables, either
the constructions materials or different materials that surround the stove (see drawing D7).
REFERENCES FLAMMABLE ITEMS NON-FLAMMABLE ITEMS
A 1500 800
B 1500 150
C 1500 400
WARNING!! It is noted that both the stove and the glass get very hot and should not be touched.
In case of is fire in the stove or smoke duct:
a. Close the loading door.
b. Put the fire out by using carbon dioxide extinguishers (CO2 powder).
c. Request for the immediate intervention of the fire-fighters.
DO NOT PUT OUT THE FIRE WITH WATER
5.2 BEAMS PROTECTION
In models Damasco and Neva, due to the amount of heat produced by
the device, you have to pay special attention to protect nearby wooden
beams. When you design your fireplace or coating both the proximity
of the beams to the exterior surfaces of the fire, and the heat emitted
from the glass door need to be taken into account. The exterior faces of
combustible beams must not be subjected to temperatures exceeding
65ºC.
Some suggested solutions to this matter appear on drawing D8.
1. Beam:
2. Refractory material isolation;
3. Pothole;
4. Metallic protection
WARNING:
The manufacturer declines any responsibility for the malfunction of an installation not subject to the requirements of these
instructions or the use of additional products not appropriate.
20 cm
A
B
C
80-120 cm
2
D7
Floor covering
(1)
(4)
(2)
(3) 10 mm
(3) 10 mm
(1)
(2)
(1)
(3) 10 mm
(2)
(1)
(2)
(3) 10-50 mm
(1)
(3) 10 mm
(2)
(4)
(2)
(1)
(3) 10 mm
D8
