Brooks Automation
24 260301 Revision A
5 Product Specifications ATR60LF RFID Reader CAN Bus
5.4 Technical Data Product Manual
5.4.1 Device Label
The device label with the CE mark, part and serial number is on the device
housing.
5.4.2 Power Supply and Current Input
1 Part number
2 Serial number (example)
3 FCC ID
Description Min Type Max Unit
Voltage (proof against connecting to
the wrong port)
18 24 30 V DC
Current (reading/writing)
pulsed current (70 ms)
100
400
mA
Current (passive) 80 mA
