BAS-311F-0 11/22
2002.1
Option parts
Ref. No. Part name Part code Q’ty
11 Outer work clamp foot, 312-2 S12644-001 1
13 Inner clamp, LL S10542-001 1
Thread wiper mechanism
Ref. No. Part name Part code Q’ty
3 Plunger pin S25456-001 1
11 Plunger pin S25456-001 1
27 Thread wiper assy, side S42859-001 1
28 Wiper arm assy S42864-101 1
29 Thread wiper, A 156206-001 1
30 Screw, SM3.57 x 10 S13385-001 1
31 Set screw, socket (CP) SM4.76 014710-522 1
32 Washer S21875-001 1
33 Collar S12668-001 1
34 Nut, 2 SM3.57 021670-202 1
35 Shoulder screw, SM3.18 100659-001 1
36 Nut, 1 SM3.18 021660-102 1
37 Spring 159111-001 1
