BAS-311F-0 12/22

2002.1

Thread wiper mechanism

Ref. No. Part name Part code Q’ty

64-9 Presser foot, XA S42849-101 1

70 Presser bar, side S42880-001 1

Thread breakage detector

Ref. No. Part name Part code Q’ty

1 TR. breakage detector set, R S43833-109 1

1-1 TR. breakage detector assy, R S43834-109 1

1-1-1 Detector bracket assy S18032-001 1

1-1-2 Disc, thread guide 144504-001 2

1-1-3 Disc, thread guide 146206-009 1

1-1-4 Pre-tension spring 146058-001 1

1-1-5 Pre-tension nut 146059-001 1

1-1-6 Spring 146060-000 1

1-1-7 Tension nut 155510-001 1

1-1-8 Pulley, A 157255-100 1

1-1-9 Washer, plain S3 025030-135 1

1-1-10 Retaining ring, E2 048020-342 1

1-1-11 Sensor assy S43835-100 1

1-1-12 Sensor cover S18037-009 1

1-1-13 Screw, pan M3 x 16 062301-616 1

1-2 Cord bush 146080-000 1
