BAS-311F-0 7/22
2002.1
For one-touch work clamp
For basting the vent
Ref. No. Part name Part code Q’ty
165 Feed plate S13092-001 1
166 Work clamp, R S13090-001 1
167 Work clamp, L S13091-001 1
For attaching the thread loop
Ref. No. Part name Part code Q’ty
168 Feed plate S13098-001 1
169 Work clamp, R S13096-001 1
170 Work clamp, L S13097-001 1
For sewing the bar tack “23 x 6”
Ref. No. Part name Part code Q’ty
171 Work clamp, R311 - 004 S23818-001 1
172 Work clamp, L311 - 004 S23819-001 1
173 Feed plate, 311 - 004 S23820-001 1
For sewing the bar tack “10.4 x 4.4”
Ref. No. Part name Part code Q’ty
174 Work clamp, R311 – 005 S23821-001 1
175 Work clamp, L311 – 005 S23822-001 1
176 Feed plate, 311 - 005 S23823-001 1
