5. PREPARATION BEFORE SEWING
25
BAS-342G PS
5-7. Home position detection
Before starting home position detection, check that the
needle bar is at the needle up stop position.
Turn the pulley (1) until the ridge at the bottom of the thread
take-up (2) is aligned with the { mark on the arm.
1. Turn on the power switch.
The POWER indicator (3) will illuminate, and the model
name [342] will appear in the PROGRAM No. display (4)
and [A-PS] will appear in the menu display (5).
After this, the program number will flash in the
PROGRAM No. display (4).
2. Depress the work clamp switch (6) to lower the work
clamp, and then depress the start switch (7). (After home
position detection is carried out, the work clamp will move
to the sewing start position and then it will rise.)
* For programs with a large number of stitches, the
buzzer will sound after the home position is detected,
and then the work clamp will move to the sewing start
position.
NOTE:
If error "E110" is displayed when the start switch (7) is
depressed, turn the pulley (1) in the direction of
operation to clear the error display.
4421Q
2574B
2918B
Aligned
4008M
4007M
2762B
To Next Page
