Options
Cassette feed attachment
Cassette support board 342G (SA9090001)
Cassette plate 342G (SA9095001)
Automatic ejector (SA9147001*
1
/SA91470E1*
2
)
It detects a cassette work clamp with the sensor and automati-
cally holds it with pneumatic cylinder drive. Automatic ejecting
of a cassette work clamp is possible by setting in sewing data.
The device can be used to improve the productivity with having
two cassette work clamps for the preparation for the next
sewing operation while sewing.
2-step thread tension device (SA7197101)
Two types of upper thread tension in each sewing program are
available by programming with the programmer (PD-3000).
The device can deal with the sewing of a pattern with the
changes of the thickness of the material such as at overlap-
ping parts or the changes of sewing direction, providing a
beautiful finish.
Thread breakage detector (SA5193101*
1
/SA51931E1*
2
)
It detects thread breakage. When thread breakage is detected,
sewing operation is stopped automatically and a warning is
given to the operator. The device is useful for simultaneous
operations of multiple sewing machines by one operator.
Floppy disk drive (FDD) set (SA5201001*
1
/ SA52010E1*
2
)
Sewing data created for the old models can be loaded to this
model machine with this set.
Option manifold 5 set (SA7500001*
1
/ SA75000E1*
2
)
It is required for the use of optional pneumatic devices.
Installing parts for work clamp / feed plate for BAS-342F
Work clamp conversion R (SA8859001)
Work clamp conversion L (SA8860001)
Feed plate conversion assy (SA8871101)
It is required when using the work clamp / feed plate for the
BAS-342F with the BAS-342G.
Thread wiper (SA5575101*
1
/SA55751E1*
2
)
It is a thread wiper driven by a pneumatic cylinder. It is to be
used when the thread is difficult to pull out of an extra-heavy
material in sewing operation.
Needle cooler (SA5559101)
It is a needle cooler which prevents thread breakage due to
heat with air. It is effective for high-speed sewing and heavy
material sewing.
Triple-pedal foot switch (SA6495101*
1
/SA64951E1*
2
)
Along with the start pedal, the right and left pedals are
provided for separated operation functions. This allows even
more precise positioning of materials.
*
1
For other than Europe *
2
For Europe only
Peripheral equipment
Sewing data programming software PS-300B
It is a software package to create, edit and modify sewing pattern data on a PC.
Complex sewing patterns can easily be created and the order of stitching of a pattern
can be checked and changed.
Gauge parts
Needle assy Needle hole plate Presser foot
Needle bar thread guide
Shuttle hook assy, w/box
Shuttle race base
Medium-weight
materials
DP×5 #16
SA1752016
φ2.2
SA5221001
<A>
S42843001
<A>
SA3257101
<LF>
SA2173301
<A>
152682201
Heavy-weight materials
(standard spec.)
DP×17 #19
SA1645019
φ2.4
SA3336101
<A>
S42843001
<A>
SA3257101
<LH>
SA8197101
<B>
152686201
Airbag
DP×17 #25
SA1645025
φ3.0
SA5222101
<B>
S42844001
<B>
SA4815101
<LH>
SA8197101
<B>
152686201
Bobbin case assy
Bobbin Spring, tension
Thread take-up spring
Spring, tension Washer
Medium-weight
materials
<LC>
S59221201
<LAN>
S44633001
104525101 145519301 SA4146101
―
Heavy-weight materials
(standard spec.)
<LC>
S59221201
<LAN>
S44633001
107606101 144588301 SA4146101
―
Airbag
<LD>
S59222201
<LB>
S15666001
107606101 144588301 SA3416101 S20681000
