xvi
Confidential
Power Cord Safety:
This product is equipped with a 3-wire grounded plug. This plug will only fit into a
grounded power outlet. This is a safety feature. DO NOT defeat the purpose of the
grounded plug.
Use only the power cord supplied with this product.
DO NOT allow anything to rest on the power cord. DO NOT place this product
where people can walk on the cord. DO NOT place this product in a position where
the cord is stretched or strain is otherwise put on the cord. Doing so may cause the
cord to become worn or frayed.
We do not advise using an extension cord.
If an extension cord is used with this product, make sure that the total ampere
ratings on the products plugged into the extension cord do not exceed the extension
cord ampere rating.
Also, make sure that the total of all products plugged into the AC power outlet does
not exceed 15 amperes. DO NOT plug one extension cord into another.
DO NOT put a toner cartridge or a toner cartridge and drum unit assembly into a
fire. It could explode, resulting in injuries.
DO NOT use flammable substances, any type of spray, or an organic solvent/liquid
containing alcohol or ammonia to clean the inside or outside of the product. Doing
so could cause a fire or electrical shock. Instead, use only a dry, lint-free cloth.
DO NOT attempt to operate this product with a paper jam or with stray pieces of paper
inside the product. Prolonged contact of the paper with the drum unit could cause a
fire.
DO NOT use a vacuum cleaner to clean up scattered toner. Doing this might cause
the toner dust to ignite inside the vacuum cleaner, potentially starting a fire. Please
carefully clean the toner dust with a dry, lint-free soft cloth and dispose of it according
to local regulations.

Table of Contents

Other manuals for Brother DCP-8150DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother DCP-8150DN and is the answer not in the manual?

Brother DCP-8150DN Specifications

General IconGeneral
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)8.5 s
Print speed (black, normal quality, A4/US Letter)40 ppm
Duplex print speed (black, normal quality, A4/US Letter)9 ppm
Copier resize25 - 400 %
Maximum copy resolution1200 x 600 DPI
Maximum number of copies99 copies
Time to first copy (black, normal)10.5 s
Scan toE-mail, File, FTP, Image, OCR, USB
Scan driversICA, TWAIN, WIA
Scanner typeFlatbed & ADF scanner
Grayscale levels256
Input color depth48 bit
Maximum scan areaLegal (216 x 356) mm
Output color depth24 bit
Maximum scan resolution19200 x 19200 DPI
FaxingNo
Printing colorsBlack
Maximum duty cycle50000 pages per month
Recommended duty cycle500 - 3500 pages per month
Number of print cartridges1
Page description languagesBR-Script 3, Epson FX, IBM ProPrinter, PCL 6
Total input capacity250 sheets
Total output capacity150 sheets
Multi-Purpose tray input capacity50 sheets
Custom media width76.2 - 215.9 mm
Maximum print size216 x 356 mm
Custom media length127 - 355.6 mm
Paper tray media typesBond paper, Envelopes, Labels, Plain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight60 - 105 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
JIS B-series sizes (B0...B9)B5
Duplex media weight (imperial)16 - 28 lbs
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 163 g/m²
Paper tray media weight (imperial)16 - 43 lbs
DisplayLCD
Market positioningBusiness
Display number of lines5 lines
Display number of characters22
Standard interfacesUSB 2.0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mobile printing technologiesApple AirPrint, Brother iPrint & Scan, Google Cloud Print
Maximum internal memory320 MB
Sound power level (standby)37 dB
Sound pressure level (printing)59 dB
Sound pressure level (quiet mode)54 dB
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)1.4 W
Power consumption (PowerSave)8.1 W
Power consumption (average operating)702 W
Package depth533.4 mm
Package width594.36 mm
Package height604.52 mm
Package weight19800 g
Mac operating systems supportedMac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supportedWindows Server 2003, Windows Server 2008
Windows operating systems supportedWindows 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Starter, Windows 7 Ultimate, Windows Vista Business, Windows Vista Enterprise, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Ultimate, Windows XP Home, Windows XP Professional, Windows XP Professional x64
Sustainability certificatesENERGY STAR
Storage temperature (T-T)0 - 40 °C
Operating temperature (T-T)10 - 32.5 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
Weight and Dimensions IconWeight and Dimensions
Depth414.02 mm
Width490.22 mm
Height447.04 mm
