Brother DCP-8150DN Service Manual

5-9
Confidential
WSW35 Function setting 13
WSW36 Function setting 14
WSW37 Function setting 15
WSW38 V.34 transmission settings
WSW39 V.34 transmission speed
WSW40 V.34 modem settings
WSW41 ON-duration of the scanning light source
WSW42 Internet mail settings
WSW43 Function setting 16
WSW44 Speeding up scanning-1
WSW45 Speeding up scanning-2
WSW46 Monitor of power ON/OFF state and parallel port kept at high
WSW47 Switching between high- and full-speed USB
WSW48 USB setup latency
WSW49 End-of-copying beep and print in black
WSW50 SDAA settings
WSW51 Function setting 17
WSW52 Function setting 18
WSW53 Function setting 19
WSW54 Function setting 20
WSW55 Interval of time required for the developing bias voltage correction
WSW56 Function setting 21
WSW57 Function setting 22
WSW58 Function setting 23
WSW59 Function setting 24
WSW60 Function setting 25
WSW61 Scanning light intensity to judge to be stable 1
WSW62 Scanning light intensity to judge to be stable 2
WSW63 Setting clock type / Demo print mode / Font support for Israel
WSW64 Setting the language / default paper size
WSW65 Setting the paper support
WSW66 Reserved (Change of the setting is prohibited)
WSW67 Reserved (Change of the setting is prohibited)
WSW68 Reserved (Change of the setting is prohibited)
WSW69 Reserved (Change of the setting is prohibited)
WSW70 Reserved (Change of the setting is prohibited)
WSW71 Reserved (Change of the setting is prohibited)
WSW72 Reserved (Change of the setting is prohibited)
WSW73 Reserved (Change of the setting is prohibited)
WSW74 ADF stop control
WSW75 Setting the document count method for duplex scanning
WSW76
Set the limit for the number of documents to be ejected in reverse order
for simplex scanning
WSW77
Set the limit for the number of documents to be ejected in reverse order
for duplex scanning from ADF
WSW78 Recording stop function when the drum reaches the end of life
WSW No. Function

Brother DCP-8150DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Time to first copy (black, normal)	10.5 s
Scan to	E-mail, File, FTP, Image, OCR, USB
Scan drivers	ICA, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	Legal (216 x 356) mm
Output color depth	24 bit
Maximum scan resolution	19200 x 19200 DPI
Faxing	No
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	500 - 3500 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Duplex media weight (imperial)	16 - 28 lbs
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Paper tray media weight (imperial)	16 - 43 lbs
Display	LCD
Market positioning	Business
Display number of lines	5 lines
Display number of characters	22
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print
Maximum internal memory	320 MB
Sound power level (standby)	37 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1.4 W
Power consumption (PowerSave)	8.1 W
Power consumption (average operating)	702 W
Package depth	533.4 mm
Package width	594.36 mm
Package height	604.52 mm
Package weight	19800 g
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Starter, Windows 7 Ultimate, Windows Vista Business, Windows Vista Enterprise, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Ultimate, Windows XP Home, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	414.02 mm
Width	490.22 mm
Height	447.04 mm
