Brother DCP-8150DN Service Manual

5-39
Confidential
Display information
*1
RTC: Real Time Clock
*2
00 : Starter toner
01 : Standard toner
02 : High yield toner
03 : Super high yield toner
1 Model name 31 Remaining life of fuser unit
2 Serial number 32 Remaining life of laser unit
3 Model code 33 Total printed pages
4 Country code 34 Total copied pages
5 Switch check sum (factory use) 35 Total printed PC pages
6 Main firmware version 36 Total printed list/fax pages
7 Sub firmware version 37 Accumulated average coverage
8
Boot firmware version
38
Average coverage by the toner cartridge
which is currently used
9 Engine firmware version 39 Drum page count
10 Panel firmware version 40 Rotations of the drum
11 Panel boot firmware version 41 Rotations of the developer roller
12 Memory version 42 Total printed pages per tray
13 ROM size 43 Total printed pages per paper size
14 ROM check sum 44 Total printed pages per paper type
15
RTC check
*1
45
Paper jams that have occurred in each
section in the machine
16 RTC backup
*1
46 Total power distribution time
17
Time before RTC backup
*1
47
The number of times that the power is
turned ON
18
Time after RTC backup
*1
48
The number of times/log that the low
temperature/low humidity mode was entered
19 USB ID code 49 Machine error log (The last 10 errors)
20
Result of function code 55
50
The number of times that consumables
have been replaced
21
Wireless LAN setting by country /
Output peak
51
Total printed pages of currently set toner
cartridge
22
Toner type
*2
52
Total printed pages of previously set
toner cartridge
23
Main PCB inspection / High-voltage
PCB inspection
53
Total pages of single side scanning
24
The number of times that the discharge
error / Fuser unit error / Polygon motor
error occurred
54
Total pages of duplex scanning
25
Not necessary for maintenance
(Factory management item)
55
Document jams that have occurred in
ADF
26
Not necessary for maintenance
(ADF sensor log)
56
Communication error log
27 Estimated remaining toner amount 57 Developing bias voltage value
28
Remaining life of drum unit
58
Not necessary for maintenance
(Development management item)
29
Remaining life of MP paper feeding kit
59
Not necessary for maintenance
(Factory management item)
30
Remaining life of paper feeding kit 1
60
Not necessary for maintenance
(Factory management item)

Brother DCP-8150DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Time to first copy (black, normal)	10.5 s
Scan to	E-mail, File, FTP, Image, OCR, USB
Scan drivers	ICA, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	Legal (216 x 356) mm
Output color depth	24 bit
Maximum scan resolution	19200 x 19200 DPI
Faxing	No
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	500 - 3500 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Duplex media weight (imperial)	16 - 28 lbs
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Paper tray media weight (imperial)	16 - 43 lbs
Display	LCD
Market positioning	Business
Display number of lines	5 lines
Display number of characters	22
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print
Maximum internal memory	320 MB
Sound power level (standby)	37 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1.4 W
Power consumption (PowerSave)	8.1 W
Power consumption (average operating)	702 W
Package depth	533.4 mm
Package width	594.36 mm
Package height	604.52 mm
Package weight	19800 g
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Starter, Windows 7 Ultimate, Windows Vista Business, Windows Vista Enterprise, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Ultimate, Windows XP Home, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	414.02 mm
Width	490.22 mm
Height	447.04 mm
