Brother DCP-8150DN Service Manual

5-41
Confidential
1.3.26 Display machine log information (function code: 80)
<Function>
This function is used to display the log information on the LCD.
<Operation Procedure>
(1) Press the [8] and [0] buttons in this order in the initial state of maintenance mode.
"USB:********" is displayed on the LCD.
(The machine serial number is displayed for *********.)
(2) Pressing the [Start] or [ ] button displays the next item.
Pressing the [ ] button returns to the previous item.
(3) When the [Stop/Exit] button is pressed, the machine returns to the initial state of
maintenance mode.
Display information
LCD *
1
Description
USB:000G8J000166 Serial number
MAC:008077112233 *
2
MAC address
PCB:911309123456 Main PCB serial number
KTN_ERM:87% Estimated remaining toner amount detected by toner sensor
KTN_RRM:67% Estimated remaining toner amount based on the rotations of
developer roller
DRUM_PG:00000000 Printed pages for drum
PFMP_PG:00000000 Pages fed from MP paper feeding kit
PFK1_PG:00000000 Pages fed from paper feeding kit 1
PFK2_PG:00000000 Pages fed from paper feeding kit 2
FUSR_PG:00000000 Printed pages for fuser unit
LASR_PG:00000000 Printed pages for laser unit
TTL_PG:00000000 Total printed pages
TTLCOPY:00000000 Total pages copied
TTLPCPT:00000000 Total pages printed via PC
TTLFAX:00000000 Total pages faxed
KCVRGUSI:4.32% Average coverage by the toner cartridge which is currently used
KCVRGACC:3.47% Accumulated average coverage
DRUM:00000000 Rotations of the drum
KTN_RND:00000000 Rotations of the developer roller
MP_PG:00000000 Pages printed from MP tray
TR1_PG:00000000 Pages printed from paper tray 1
DX_PG:00000000 Duplex printed pages
TR2_PG:00000000 Pages printed from paper tray 2
A4+LTR:00000000 Printed pages of A4 size and Letter size paper
LG+FOL:00000000 Printed pages of Legal size and Folio size paper
B5+EXE:00000000 Printed pages of B5 size and EXE size paper

Brother DCP-8150DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Time to first copy (black, normal)	10.5 s
Scan to	E-mail, File, FTP, Image, OCR, USB
Scan drivers	ICA, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	Legal (216 x 356) mm
Output color depth	24 bit
Maximum scan resolution	19200 x 19200 DPI
Faxing	No
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	500 - 3500 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
JIS B-series sizes (B0...B9)	B5
Duplex media weight (imperial)	16 - 28 lbs
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Paper tray media weight (imperial)	16 - 43 lbs
Display	LCD
Market positioning	Business
Display number of lines	5 lines
Display number of characters	22
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print
Maximum internal memory	320 MB
Sound power level (standby)	37 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1.4 W
Power consumption (PowerSave)	8.1 W
Power consumption (average operating)	702 W
Package depth	533.4 mm
Package width	594.36 mm
Package height	604.52 mm
Package weight	19800 g
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Starter, Windows 7 Ultimate, Windows Vista Business, Windows Vista Enterprise, Windows Vista Home Basic, Windows Vista Home Premium, Windows Vista Ultimate, Windows XP Home, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	414.02 mm
Width	490.22 mm
Height	447.04 mm
