1.2 List of Maintenance-mode Functions
Shaded maintenance mode functions are available to end users.
* Exclusive to the end user-accessible maintenance mode.
Maintenance
Mode
Function
Reference Section
(Page)
01 EEPROM Parameter Initialization 1.3.1 (5-5)
02 Creating of Head Calibration Data and Writing it into Flash ROM 1.3.2 (5-6)
05 Printout of Scanning Compensation White/Black Level Data 1.3.3 (5-11)
08 ADF Performance Test 1.3.4 (5-14)
09 Printout of Test Pattern 1.3.5 (5-14)
10 Worker Switch (WSW) Setting 1.3.6 (5-16)
11 Printout of Worker Switch (WSW) Data 1.3.6 (5-16)
12 Operational Check of LCD 1.3.7 (5-19)
13 Operational Check of Keys on Control Panel 1.3.8 (5-20)
17 * EEPROM Dump and Log Information Transfer 1.3.9 (5-21)
28 Updating of Firmware Using an External Memory 1.3.10 (5-22)
32 Sensor Operational Check 1.3.11 (5-23)
37 * Printout of Dial Log 1.3.12 (5-25)
46 Backup of Machine Information 1.3.13 (5-26)
52 Setting of Country/Language 1.3.14 (5-28)
53 Transfer of Received FAX Data and/or Equipment's Log 1.3.15 (5-29)
54 Fine Adjustment of Scanning Position 1.3.16 (5-31)
55
Acquisition of White/Black Level Data and CIS Scanner Area
Setting
1.3.17 (5-32)
57 Cartridge IC Communication Check 1.3.18 (5-33)
58 Updating of Paper Feeding Correction Values 1.3.19 (5-34)
59 Checking of CIS Travel and Setting of CIS Type 1.3.20 (5-40)
61 Print of PRN/JPEG Files in Memory Card 1.3.21 (5-41)
63 Move of the Head/Carriage Unit to the Adjustment Position 1.3.22 (5-42)
65
Adjustment of Vertical Print Lines/Software Correction for
Inclination/Corrugation/Ruled Lines
1.3.23 (5-43)
66 Margin Adjustment in Borderless Printing 1.3.24 (5-47)
68
Updating of Head Property Data and Backup/Restoration of Head
Calibration Data
1.3.25 (5-49)
69 Traveling Speed Check of Head/Carriage Unit 1.3.26 (5-51)
74 Customizing Destinations 1.3.27 (5-52)
75 Move of the Head/Carriage Unit to the Center 1.3.28 (5-55)
76 Purge Operation 1.3.29 (5-56)
77 Print of the Maintenance Information 1.3.30 (5-59)
78 Adjustment of Touch Panel 1.3.31 (5-61)
80 Display of the Equipment's Log 1.3.32 (5-62)
82 Equipment Error Code Indication 1.3.33 (5-65)
87 Output of Transmission Log to the Telephone Line 1.3.34 (5-65)
88 Assurance Mode Switch Setting (AMS) 1.3.35 (5-66)
91 EEPROM Parameter Initialization 1.3.1 (5-5)
99 Exit from the Maintenance Mode
