1.3.11Display LAN connection status (function code: 33)

This function is used to check the connection status of the wired LAN.

(1) Press the [3] key twice in the initial state of maintenance mode. One of the following

items is displayed on the LCD depending on the wired LAN connection of the machine.

(2) Press the [X] key, and the machine returns to the initial state of maintenance mode.

LCD LAN connection status

Active 100B-FD 100B-FD

Active 100B-HD 100B-HD

Active 10B-FD 10B-FD

Active 10B-HD 10B-HD

Inactive Not connected
