Page #125 background imageLoading...
Page #125 background image
Troubleshooting
115
7
Error messages in the Status Monitor 7
The Status Monitor will report problems with the printer. Take the necessary action by referring to the
following table.
If you want to turn the status monitor on, see Status Monitor on page 47 (For Windows
®
user) or Status
Monitor on page 62(For Macintosh
®
users).
Error message Action
Cartridge Position
Error
Put the drum unit assembly back in.
Drum End Soon The drum unit is near the end of its life. Buy a new drum unit to replace the current one.
See Replacing the drum unit on page 101.
Replace Drum See Replacing the drum unit on page 101
Duplex Disabled Close the back cover of the printer and put the duplex tray back in.
Drum Error See Cleaning the corona wire on page 112.
Front Cover is Open Close the front cover of the printer.
Fuser Cover is Open Close the fuser cover located behind the back cover of the printer.
Incorrect paper size
for auto DX
Press Go or Job Cancel. Set the correct paper that you want to use, or load the same
size paper that you selected in the current driver setting. The paper size you can use for
automatic duplex printing is A4, Letter, Legal or Folio.
Jam MP Tray
Jam Tray 1
Jam Tray 2
Jam Tray 3
Jam Inside
Jam Rear
Jam Duplex
Clear the jammed paper from the indicated area. See Paper jams and how to clear them
on page 119.
Memory Full Press Go to print the remaining data in the printer memory. Cancel the print job if you
want to delete the remaining data in the printer memory. See Control panel buttons on
page 83.
Reduce the complexity of your document or cut the print resolution.
Add more memory. See Installing extra memory on page 90.
No Toner Open the front cover, then install the toner cartridge.
Downloaded from ManualsPrinter.com Manuals

Table of Contents

Other manuals for Brother HL-5350DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother HL-5350DN and is the answer not in the manual?

Brother HL-5350DN Specifications

General IconGeneral
ColorNo
N-up printing4, 9, 16, 25
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Economical printingYes
Time to first page (black, normal)8.5 s
Print speed (black, normal quality, A4/US Letter)30 ppm
Internal memory32 MB
Processor modelNEC VR5500
Maximum internal memory544 MB
Sound power level (standby)35 dB
Sound pressure level (printing)54 dB
Total input capacity250 sheets
Total output capacity150 sheets
Multi-Purpose tray input capacity50 sheets
Maximum print size216 x 356 mm
Media weight (tray 1)60 - 105 g/m²
Non-ISO print media sizesLetter
ISO A-series sizes (A0...A9)A4, A5, A6
ISO B-series sizes (B0...B9)B5, B6
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 163 g/m²
Supported network protocols (IPv4)IPv4: ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD responder, WebServicesPrint, IPv6: NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS server, SSL/TLS, TFTP client and server, SMTP Client, APOP, POP before SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMPv6, LLTD responder, WebServicesPrint
Networking features10/100 Base-TX
Power consumption (active)675 W
Compatible operating systemsWindows: Vista, 2000 Prof., XP Home Edition, XP Prof. Edition (32 & 62 bits), Server 2003 (32 & 64 bits), Server 2008. MacIntosh: Mac OS X 10.3.9 + Linux
Power consumption (standby)75 W
Power consumption (PowerSave)6 W
Package weight11500 g
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)371 x 384 x 246 mm
