Level 2 Level 3 Level 4 Level 5 Descriptions
WLAN TCP/IP WINS Server
Secondary
Specify the IP address of the secondary
WINS server.
DNS Server Primary
Specify the primary DNS server's IP
address.
Secondary
Specify the secondary DNS server's IP
address.
IP Boot Tries
- Specify the number of attempts the
machine will try to obtain an IP address
when the Boot Method is set to any
setting except Static.
APIPA
- Allocate the IP address from the link-local
address range automatically
1
.
IPv6
- Enable or disable the IPv6 protocol.
Setup Wizard
- - Configure the wireless network settings
using the setup wizard.
WLAN
Assistant
- - Configure your wireless network settings
using the Brother CD-ROM.
WPS
- - Configure your wireless network settings
using the one-button push method.
WPS w/ PIN
Code
- - Configure the wireless network settings
using WPS with a PIN code.
WLAN Status Status
- Display the wireless Ethernet link status.
Signal
- Display the signal condition.
SSID
- Display SSID.
Comm. Mode
- Display the current Communication
Mode.
MAC Address
- - Display the MAC address of the machine.
Set to
Default
- - Restore wireless network settings of your
machine to the factory settings.
WLAN Enable
- - Turn the wireless interface on or off.
Wi-Fi Direct Push Button
- - Configure your Wi-Fi Direct network
settings using the one-button push
method quickly.
PIN Code
- - Configure your Wi-Fi Direct network
settings using WPS with a PIN code
quickly.
Manual
- - Configure your Wi-Fi Direct network
settings manually.
Group Owner
- - Set your machine as the Group Owner.
Device Info. Device Name
- View your machine's device name.
SSID
- Display the Group Owner's SSID.
IP Address
- Display your machine's IP Address.
Status Info. Status
- Display the Wi-Fi Direct network status.
Signal
- Display the current Wi-Fi Direct network
signal strength.
I/F Enable
- - Enable or disable the Wi-Fi Direct
connection.
NFC
- - - Turn the NFC function on or off.
339

Table of Contents

Other manuals for Brother HL-L5100DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother HL-L5100DN and is the answer not in the manual?

Brother HL-L5100DN Specifications

General IconGeneral
ColorNo
N-up printing2, 4, 9, 16, 25
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Duplex printing modeAuto
Time to first page (black, normal)7.2 s
Print speed (black, normal quality, A4/US Letter)40 ppm
PCL fonts66
Printer fontsBitmap, PostScript
Printing colorsBlack
Maximum duty cycle50000 pages per month
Recommended duty cycle0 - 3500 pages per month
Number of print cartridges1
Page description languagesBR-Script 3, Epson FX, IBM ProPrinter, Microsoft XPS, PCL 6, PDF 1.7, PostScript 3
DisplayLCD
CertificationNordic Swan
Product colorGraphite
Market positioning-
Display number of lines1 lines
AC input frequency50 - 60 Hz
Power consumption (off)0.04 W
Power consumption (standby)32 W
Power consumption (printing)620 W
Energy Star Typical Electricity Consumption (TEC)1.763 kWh/week
Processor modelA9
Processor familyARM Cortex
Maximum internal memory- MB
Sound power level (standby)34 dB
Sound pressure level (printing)52 dB
Sound pressure level (quiet mode)50 dB
Paper input typeCassette, Paper tray
Total input capacity250 sheets
Total output capacity150 sheets
Multi-Purpose tray input capacity50 sheets
Custom media width76.2 - 215.9 mm
Custom media length127 - 355.6 mm
Paper tray media typesPlain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight60 - 120 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
Duplex media weight (imperial)60 - 120 lbs
Multi-purpose tray media typesBond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 200 g/m²
Storage temperature (T-T)0 - 40 °C
Operating temperature (T-T)10 - 32 °C
Storage relative humidity (H-H)35 - 85 %
Operating relative humidity (H-H)20 - 80 %
Cabling technology10/100Base-T(X)
Security algorithms802.1x RADIUS, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, IPSEC, PEAP, SMTP-AUTH, SNMP, SSL/TLS
Ethernet LAN data rates10, 100 Mbit/s
Mobile printing technologiesApple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS Server, TFTP Client & Server, SMTP Client, SNMPv1/v2c/v3, ICMP, Web Services (Print), CIFS Client, SNTP Client
Supported network protocols (IPv6)NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS Server, TFTP Client & Server, SMTP Client, SNMPv1/v2c, ICMPv6, Web Services (Print), CIFS Client, SNTP Client
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Package depth450 mm
Package width485 mm
Package height377 mm
Package weight13000 g
Sustainability certificatesBlue Angel, ENERGY STAR
Server operating systems supportedWindows Server 2003, Windows Server 2008, Windows Server 2012
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Email protocolsSMTP
Harmonized System (HS) code84433210
Weight and Dimensions IconWeight and Dimensions
Depth388 mm
Width373 mm
Height255 mm
