Page #359 background imageLoading...
Page #359 background image
2-sided Automatic 2-sided
Printing
Letter, Legal, Mexico Legal, India Legal, Folio
Paper Weight
60 to 105 g/m
2
Printer Specifications
Automatic 2-sided Print Yes
Emulation PCL6, BR-Script3, IBM Proprinter XL, Epson FX-850, PDF version1.7, XPS version
1.0
Resolution Up to 1200 x 1200 dpi
Print Speed
9
10
1-sided
print
(HL-L5000D/HL-L5100DN/HL-L5200DW)
Up to 42 pages/minute (Letter size)
Up to 40 pages/minute (A4 size)
(For Australia and New Zealand)
(HL-L6200DW)
Up to 48 pages/minute (Letter size)
Up to 46 pages/minute (A4 size)
(HL-L6400DW)
Up to 52 pages/minute (Letter size)
Up to 50 pages/minute (A4 size)
(For Other countries)
(HL-L6200DW/HL-L6400DW)
Up to 52 pages/minute (Letter size)
Up to 50 pages/minute (A4 size)
2-sided
Print
(HL-L5000D/HL-L5100DN/HL-L5200DW)
Up to 20 sides/minute (Up to 10 sheets/minute) (Letter or A4 size)
(HL-L6200DW/HL-L6400DW)
Up to 24 sides/minute (Up to 12 sheets/minute) (Letter or A4 size)
First Print Time
11
(HL-L5000D/HL-L5100DN/HL-L5200DW)
(For Taiwan)
Less than 7.2 seconds at 23 °C / 115 V
(Except Taiwan)
Less than 7.2 seconds at 23 °C / 230 V
(HL-L6200DW/HL-L6400DW)
(For Taiwan)
Less than 7.5 seconds at 23 °C / 115 V
(Except Taiwan)
Less than 7.5 seconds at 23 °C / 230 V
Interface Specifications
Parallel
12
HL-L5000D Compliant with IEEE1284
USB
13 14
All Hi-Speed USB 2.0
Use a USB 2.0 interface cable that is no longer than 6 ft (2 m).
9
The print speed may change depending on the type of document you print.
10
Print speed may be slower when the machine is connected by wireless LAN.
11
From Ready mode and standard tray
12
If the parallel cable is not provided with the machine in your country or region, please contact Brother customer service or your local Brother
dealer to purchase the optional parallel cable (PC-5000).
13
Your machine has a USB 2.0 Hi-Speed interface. The machine can also be connected to a computer that has a USB 1.1 interface.
14
Third party USB ports are not supported.
354

Table of Contents

Other manuals for Brother HL-L5100DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother HL-L5100DN and is the answer not in the manual?

Brother HL-L5100DN Specifications

General IconGeneral
ColorNo
N-up printing2, 4, 9, 16, 25
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Duplex printing modeAuto
Time to first page (black, normal)7.2 s
Print speed (black, normal quality, A4/US Letter)40 ppm
PCL fonts66
Printer fontsBitmap, PostScript
Printing colorsBlack
Maximum duty cycle50000 pages per month
Recommended duty cycle0 - 3500 pages per month
Number of print cartridges1
Page description languagesBR-Script 3, Epson FX, IBM ProPrinter, Microsoft XPS, PCL 6, PDF 1.7, PostScript 3
DisplayLCD
CertificationNordic Swan
Product colorGraphite
Market positioning-
Display number of lines1 lines
AC input frequency50 - 60 Hz
Power consumption (off)0.04 W
Power consumption (standby)32 W
Power consumption (printing)620 W
Energy Star Typical Electricity Consumption (TEC)1.763 kWh/week
Processor modelA9
Processor familyARM Cortex
Maximum internal memory- MB
Sound power level (standby)34 dB
Sound pressure level (printing)52 dB
Sound pressure level (quiet mode)50 dB
Paper input typeCassette, Paper tray
Total input capacity250 sheets
Total output capacity150 sheets
Multi-Purpose tray input capacity50 sheets
Custom media width76.2 - 215.9 mm
Custom media length127 - 355.6 mm
Paper tray media typesPlain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight60 - 120 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
Duplex media weight (imperial)60 - 120 lbs
Multi-purpose tray media typesBond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 200 g/m²
Storage temperature (T-T)0 - 40 °C
Operating temperature (T-T)10 - 32 °C
Storage relative humidity (H-H)35 - 85 %
Operating relative humidity (H-H)20 - 80 %
Cabling technology10/100Base-T(X)
Security algorithms802.1x RADIUS, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, IPSEC, PEAP, SMTP-AUTH, SNMP, SSL/TLS
Ethernet LAN data rates10, 100 Mbit/s
Mobile printing technologiesApple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS Server, TFTP Client & Server, SMTP Client, SNMPv1/v2c/v3, ICMP, Web Services (Print), CIFS Client, SNTP Client
Supported network protocols (IPv6)NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS Server, TFTP Client & Server, SMTP Client, SNMPv1/v2c, ICMPv6, Web Services (Print), CIFS Client, SNTP Client
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Package depth450 mm
Package width485 mm
Package height377 mm
Package weight13000 g
Sustainability certificatesBlue Angel, ENERGY STAR
Server operating systems supportedWindows Server 2003, Windows Server 2008, Windows Server 2012
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Email protocolsSMTP
Harmonized System (HS) code84433210
Weight and Dimensions IconWeight and Dimensions
Depth388 mm
Width373 mm
Height255 mm
