Page #378 background imageLoading...
Page #378 background image
To use DHCP, contact your network administrator.
DNS Client
The Brother print server supports the Domain Name System (DNS) client feature. This feature allows the print
server to communicate with other devices using its DNS name.
DNS Server
The Domain Name System (DNS) is a technology to manage the names of web sites and internet domains. A
DNS server allows your computer to find its IP address automatically.
Driver Deployment Wizard
Brother's Installation CD-ROM includes the Windows
®
printer driver and Brother network port driver (LPR and
NetBIOS). If an administrator installs the printer driver and port driver using this application, the administrator can
save the file to the file server or send the file by email to users. Then, each user just clicks that file to have the
printer driver, port driver, IP address, etc. automatically copied to their computer.
Encryption
Most wireless networks use some kind of security settings. These security settings define the authentication (how
the device identifies itself to the network) and encryption (how the data is encrypted as it is sent on the network).
If you do not correctly specify these options when you are configuring your Brother wireless machine, it will not
be able to connect to the wireless network. Therefore, care must be taken when configuring these options.
Encryption Methods for a Personal Wireless Network
A personal wireless network is a small network (such as a home wireless network) without IEEE 802.1x
support.
None
No encryption method is used.
WEP
When using Wired Equivalent Privacy (WEP) the data is transmitted and received with a secured key.
TKIP
Temporal Key Integrity Protocol (TKIP) provides per-packet key mixing a message integrity check and
rekeying mechanism.
AES
Advanced Encryption Standard (AES) provides stronger data protection using a symmetric-key encryption.
IEEE 802.11n does not support either WEP or TKIP as an encryption method.
To connect to your wireless network using IEEE 802.11n, we recommend selecting AES.
Encryption Methods for an Enterprise Wireless Network
An enterprise wireless network is a large network, for example using your machine in a business enterprise
wireless network, with IEEE 802.1x support. If you configure your machine in an IEEE 802.1x supported
wireless network, you can use the following encryption methods.
TKIP
AES
CKIP
Home > Glossary
373

Table of Contents

Other manuals for Brother HL-L5100DN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother HL-L5100DN and is the answer not in the manual?

Brother HL-L5100DN Specifications

General IconGeneral
ColorNo
N-up printing2, 4, 9, 16, 25
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Duplex printing modeAuto
Time to first page (black, normal)7.2 s
Print speed (black, normal quality, A4/US Letter)40 ppm
PCL fonts66
Printer fontsBitmap, PostScript
Printing colorsBlack
Maximum duty cycle50000 pages per month
Recommended duty cycle0 - 3500 pages per month
Number of print cartridges1
Page description languagesBR-Script 3, Epson FX, IBM ProPrinter, Microsoft XPS, PCL 6, PDF 1.7, PostScript 3
DisplayLCD
CertificationNordic Swan
Product colorGraphite
Market positioning-
Display number of lines1 lines
AC input frequency50 - 60 Hz
Power consumption (off)0.04 W
Power consumption (standby)32 W
Power consumption (printing)620 W
Energy Star Typical Electricity Consumption (TEC)1.763 kWh/week
Processor modelA9
Processor familyARM Cortex
Maximum internal memory- MB
Sound power level (standby)34 dB
Sound pressure level (printing)52 dB
Sound pressure level (quiet mode)50 dB
Paper input typeCassette, Paper tray
Total input capacity250 sheets
Total output capacity150 sheets
Multi-Purpose tray input capacity50 sheets
Custom media width76.2 - 215.9 mm
Custom media length127 - 355.6 mm
Paper tray media typesPlain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight60 - 120 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
Duplex media weight (imperial)60 - 120 lbs
Multi-purpose tray media typesBond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 200 g/m²
Storage temperature (T-T)0 - 40 °C
Operating temperature (T-T)10 - 32 °C
Storage relative humidity (H-H)35 - 85 %
Operating relative humidity (H-H)20 - 80 %
Cabling technology10/100Base-T(X)
Security algorithms802.1x RADIUS, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, IPSEC, PEAP, SMTP-AUTH, SNMP, SSL/TLS
Ethernet LAN data rates10, 100 Mbit/s
Mobile printing technologiesApple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS Server, TFTP Client & Server, SMTP Client, SNMPv1/v2c/v3, ICMP, Web Services (Print), CIFS Client, SNTP Client
Supported network protocols (IPv6)NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS Server, TFTP Client & Server, SMTP Client, SNMPv1/v2c, ICMPv6, Web Services (Print), CIFS Client, SNTP Client
Standard interfacesEthernet, USB 2.0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Package depth450 mm
Package width485 mm
Package height377 mm
Package weight13000 g
Sustainability certificatesBlue Angel, ENERGY STAR
Server operating systems supportedWindows Server 2003, Windows Server 2008, Windows Server 2012
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Email protocolsSMTP
Harmonized System (HS) code84433210
Weight and Dimensions IconWeight and Dimensions
Depth388 mm
Width373 mm
Height255 mm
