Brother HL-L5100DN User Manual

Print with Google Cloud Print
™
.................................................................................................................. 236
Print with AirPrint........................................................................................................................................ 237
Print with Mopria
™
...................................................................................................................................... 238
Print from a Mobile Device ......................................................................................................................... 239
Print Using Near-Field Communication (NFC) ........................................................................................... 240
Troubleshooting ................................................................................................................................ 241
Error and Maintenance Messages ............................................................................................................. 242
Paper Jams ................................................................................................................................................ 250
Paper is Jammed in the MP tray ...................................................................................................... 251
Paper is Jammed in the Paper Tray ................................................................................................. 252
Paper is Jammed in the Back of the Machine .................................................................................. 254
Paper is Jammed inside the Machine .............................................................................................. 256
Paper is Jammed in the 2-sided Tray............................................................................................... 258
Paper is Jammed in the Mailbox Unit............................................................................................... 260
Printing Problems....................................................................................................................................... 261
Improve the Print Quality............................................................................................................................ 263
Network Problems...................................................................................................................................... 267
Error Messages ................................................................................................................................ 268
Use the Network Connection Repair Tool (Windows
®
) .................................................................... 271
Where Can I Find My Brother Machine's Network Settings? ........................................................... 273
I Cannot Complete the Wireless Network Setup Configuration........................................................ 274
My Brother Machine Cannot Print over the Network ........................................................................ 276
I Want to Check that My Network Devices are Working Correctly ................................................... 278
Other Problems .......................................................................................................................................... 279
Check the Machine Information ................................................................................................................. 281
Reset Functions ......................................................................................................................................... 283
Network Reset.................................................................................................................................. 284
Factory Reset ................................................................................................................................... 285
Routine Maintenance ........................................................................................................................ 286
Replace Supplies ....................................................................................................................................... 287
Replace the Toner Cartridge ............................................................................................................ 290
Replace the Drum Unit ..................................................................................................................... 293
Clean the Machine ..................................................................................................................................... 295
Clean the Touchscreen LCD ............................................................................................................ 297
Clean the Corona Wire..................................................................................................................... 298
Clean the Drum Unit......................................................................................................................... 299
Clean the Paper Pick-up Rollers ...................................................................................................... 305
Check the Remaining Life of Parts............................................................................................................. 306
Pack and Ship Your Machine ..................................................................................................................... 307
Pack the Machine and the Toner Cartridge Together ....................................................................... 308
Pack the Machine and the Toner Cartridge Separately.................................................................... 310
Machine Settings............................................................................................................................... 313
Change Machine Settings from the Control Panel ..................................................................................... 314
General Settings............................................................................................................................... 315
Settings and Features Tables........................................................................................................... 325
Change Machine Settings from Your Computer......................................................................................... 342
Home > Table of Contents
iii

Brother HL-L5100DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	7.2 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
PCL fonts	66
Printer fonts	Bitmap, PostScript
Printing colors	Black
Maximum duty cycle	50000 pages per month
Recommended duty cycle	0 - 3500 pages per month
Number of print cartridges	1
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, Microsoft XPS, PCL 6, PDF 1.7, PostScript 3
Display	LCD
Certification	Nordic Swan
Product color	Graphite
Market positioning	-
Display number of lines	1 lines
AC input frequency	50 - 60 Hz
Power consumption (off)	0.04 W
Power consumption (standby)	32 W
Power consumption (printing)	620 W
Energy Star Typical Electricity Consumption (TEC)	1.763 kWh/week
Processor model	A9
Processor family	ARM Cortex
Maximum internal memory	- MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	52 dB
Sound pressure level (quiet mode)	50 dB
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper, Thick paper, Thin paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
Duplex media weight (imperial)	60 - 120 lbs
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Letterhead, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 200 g/m²
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	35 - 85 %
Operating relative humidity (H-H)	20 - 80 %
Cabling technology	10/100Base-T(X)
Security algorithms	802.1x RADIUS, EAP-FAST, EAP-MD5, EAP-TLS, EAP-TTLS, HTTPS, IPPS, IPSEC, PEAP, SMTP-AUTH, SNMP, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS Server, TFTP Client & Server, SMTP Client, SNMPv1/v2c/v3, ICMP, Web Services (Print), CIFS Client, SNTP Client
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, FTP Server, TELNET Server, HTTP/HTTPS Server, TFTP Client & Server, SMTP Client, SNMPv1/v2c, ICMPv6, Web Services (Print), CIFS Client, SNTP Client
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Package depth	450 mm
Package width	485 mm
Package height	377 mm
Package weight	13000 g
Sustainability certificates	Blue Angel, ENERGY STAR
Server operating systems supported	Windows Server 2003, Windows Server 2008, Windows Server 2012
Windows operating systems supported	Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
Email protocols	SMTP
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	388 mm
Width	373 mm
Height	255 mm
