6. USING THE OPERATION PANEL (ADVANCED OPERATIONS)
KE-430D, BE-438D 45
6-7. Using cycle programs
Sewing patterns that have been recorded in user programs can be recorded in up to nine cycle programs (C-1 to C-9).
One cycle program can contain up to a maximum of fifteen steps.
When sewing the sewing patterns in numerical order, it can be useful to record them in a cycle program beforehand.
Cycle programs are enabled when memory switch nos. 400 and 401 are set to "ON".
<Recording the cycle programs>
1
Switch to user program recording mode.
TEST indicator lights
Menu indicators flash
While pressing the TEST key, press the SELECT key.
• Check that the menu indicators are flashing.
• User program number will appear in the PROGRAM
No. display, and the program number will appear in the
menu display.
Record the sewing patterns into a user program so that
they can be recorded in a cycle program.
2
Switch to cycle program recording mode, and select
the cycle program number.
Menu indicators switch off
Press a function key from F1 to F4.
• Cycle program number will appear in the PROGRAM
No. display, and “ 1. - - - ” will appear in the menu
display.
Press a function key from F1 to F4, or press the
or
key to select a cycle program number.
3
Set the step 1.
Press the
or key to set the program number that
you would like to record.
Press the SELECT key.
4
Set the rest of the steps in the same way from step 2 onward.
From step 9 onward, "A.---", "b.---", "c.---", "d.---", "E.---" and "F.---" will be displayed.
If you would like to return to a previous step during the setting procedure
<For cycle programs C-1 to C-4>
1. Press the respective function key from F1 to F4 to return to the display for step 1.
2. Press the SELECT key until the desired step is reached.
<For cycle programs C-5 to C-9>
1. Press the
or key to change the cycle program number.
2. Select the desired cycle program number again, and then press the SELECT key until the desired step is reached.
4481Q
4428Q
4444Q
