Brother MFC 6890CDW Quick Setup Guide

7
5
Check the print quality
a When the preparation process has finished, the
LCD shows this message
.
Press Color Start.
b Check the quality of the four color blocks a on
the sheet. (black/yellow/cyan/magenta)
c If all lines are clear and visible, press Yes to
finish the quality check.
If you can see missing short lines, press No and
go to d.
d The LCD asks you if the print quality is OK for
black and color. Press Yes or No.
After pressing Yes or No for both black and
color, the LCD shows:
e Press Color Start, the machine will then start
cleaning the colors.
f After cleaning is finished, press Color Start.
The machine starts printing the Print Quality
Check Sheet again. Go back to b.
6
Choose your language
(If needed)
a Press MENU.
b Press a or b to display Initial Setup.
c Press Initial Setup.
d Press a or b to display Local Language.
e Press Local Language.
f Press your language.
g Press Stop/Exit.
Important
Make sure you put paper in the upper tray for
the initial setup.
<Black> <Color>
OK OK
<Black> <Color>
Poor Poor
Set Paper and Press Start
1
1
Black OK?
Yes No
Start Cleaning?
Press Start

Brother MFC 6890CDW Specifications

General

Print technology	Inkjet
Maximum resolution	6000 x 1200 DPI
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	28 ppm
Digital sender	No
Number of print cartridges	4
Scan to	E-mail, FTP, USB
Duplex scanning	Yes
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, PNG
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	23 cpm
Copy speed (color, normal quality, A4)	20 cpm
Faxing	Color faxing
Fax memory	480 pages
Modem speed	33.6 Kbit/s
Total input capacity	350 sheets
Total output capacity	50 sheets
Display diagonal	4.2 \
Market positioning	Home & office
Processor family	RISC
Sound pressure level (printing)	50 dB
Media weight (tray 1)	64 - 220 g/m²
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B4, B5
Borderless printing media sizes	A3, A4, A6
Maximum ISO A-series paper size	A3
Scan speed	4.49 sec/page
Dimensions (WxDxH)	540 x 488 x 323 mm
Power requirements	AC 220 -240V, 50/60Hz
Networking features	10/100 Base-TX
Wireless technology	802.11b/g
All-in-one functions	Copy, Fax, Scan
Color all-in-one functions	copy, fax, print, scan
Compatible operating systems	Windows: Vista, 2000 Prof., XP Home Edition/Prof. Edition (32 & 62 bits), Server 2003 (32 & 64 bits), Server 2008. Mac OS X 10.2 & later Linux: for CUPS printing system (x86, x64 environment) Printer & scanner driver
Supported network protocols (IPv4)	IPv4: ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), NetBIOS/WINS, LPR/LPD, Custom Raw Port/Port9100, DNS Resolver, mDNS, FTP Server, TELNET, SNMPv1, TFTP, Scanner Port, LLTD, responder, Web Services, SMTP Client, POP before SMTP, SMTP-AUTH, POP3, APOP, FTP Client, LDAP
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	6.4 W
Power consumption (PowerSave)	4.5 W
Power consumption (average operating)	29 W
Operating relative humidity (H-H)	20 - 80 %
Package weight	22100 g
Bundled software	Brother MFL-pro suite in Windows: BrotherControlCentre 3 Scansoft Paperport 11SE + OCR, Macintosh:BrotherControlCentre 2 Newsoft Presto! Page manager 7
