Brother MFC-8480DN - B/W Laser - All-in-One Quick Setup Guide

28
Macintosh
Wired Network
For Wired Network Interface Users
(Mac OS X 10.3.9 or greater)
17
Before you install
a Make sure your machine is connected to the
power and your Macintosh is ON. You must be
logged on with Administrator rights.
18
Connect the network
cable
a Connect the network interface cable to the LAN
connector marked with a symbol and then
connect it to a free port on your hub.
19
Install MFL-Pro Suite
a Put the supplied CD-ROM into your CD-ROM
drive.
b Double-click Start Here OSX to install.
Please wait, it will take a few seconds for the
software to install. After the installation, click
Restart to finish installing the software.
c The Brother software will search for the Brother
device. During this time the following screen
will appear.
IMPORTANT
Make sure a USB Flash memory device is not
inserted into the machine.
Note
Please see the Network User’s Guide on the
CD-ROM if you want to install the PS driver.
(Brother’s BR-Script Driver)

Brother MFC-8480DN - B/W Laser - All-in-One Specifications

General

Printer Type	B/W Laser
Functions	Print, Copy, Scan, Fax
Scan Resolution	Up to 19200 x 19200 dpi (interpolated)
Automatic Duplex Printing	Yes
Connectivity	USB 2.0, Ethernet
Paper Input Capacity	250 sheets
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Print Speed	32 ppm
Copy Resolution	1200 x 600 dpi
Scan Type	Flatbed, ADF
Max Paper Size	Legal (8.5 in x 14 in)
Print Resolution	1200 x 1200 dpi
Copy Speed	Up to 32 cpm
Dimensions	531 mm x 451 mm x 475 mm
