Brother MFC-8480DN Parts Reference List

LIST12(PANEL)
REF No. CODE Q'TY DESCRIPTION
RECOMMEND
SYMBO
L
REMARKS
1 LS7312001 1 PANEL UNIT, DCP8080DN/DCP8085DN EXCEPT FOR CHN
1 LS7247001 1 PANEL UNIT, MFC8480DN/MFC8680DN/MFC8880DN/MFC8881DNHY/
MFC8890DW EXCEPT FOR CHN
1 LX2064001 1 PANEL UNIT, DCP8085DN FOR CHN
1 LS7929001 1 PANEL UNIT, MFC8880DN FOR CHN
1-1 LS7313001 1 PRINTED RUBBER KEY, DCP8080DN/DCP8085DN
1-1 LS7272001 1 PRINTED RUBBER KEY, MFC8480DN/MFC8680DN/MFC8880DN/
MFC8881DNHY/MFC8890D
W
1-2 LT069500
2
1 PANEL PCB ASSY, DCP8080DN/DCP8085DN EXCEPT FOR CH
N
B57T005
1-2 LT0695001 1 PANEL PCB ASSY, MFC8480DN/MFC8680DN/MFC8880DN/
MFC8881DNHY/MFC8890DW EXCEPT FOR CHN
B53K852
1-2 LT096400
2
1 PANEL PCB ASSY, DCP8085DN FOR CHN
B57T001
A
DD
1-2 LT0964001 1 PANEL PCB ASSY, MFC8880DN FOR CH
N
B57T001
1-3
A
62006001 1 LCD EXCEPT FOR CHN
1-3
A
62027001 1 LCD FOR CHN
1-4 LG6550001 1 BACK LIGHT MODULE
1-5 LF9709001 1 LCD COVER
1-6 LX2082001 1 PANEL INSULATION SHEET add
2 LS7309001 1 PANEL COVER ASSY, DCP8080DN FOR US/CAN
2 LS7608001 1 PANEL COVER ASSY, DCP8085DN FOR US/UK/FRA/BEL/NLD/ARL/NZ/
PND/EEU
(
ENGLISH
)
2 LS7316001 1 PANEL COVER ASSY, MFC8480DN FOR US/CAN
2 LX2013001 1 PANEL COVER ASSY, MFC8680DN FOR U
S
2 LS7248001 1 PANEL COVER ASSY, MFC8890DW FOR US/CAN/ARL/NZ
2 LS7674001 1 PANEL COVER ASSY, DCP8085DN FOR GER/CHE
2 LS7667001 1 PANEL COVER ASSY, MFC8880DN FOR GER/CHE/AU
S
2 LS7679001 1 PANEL COVER ASSY, MFC8890DW FOR GER/CHE/AUS
2 LS7563001 1 PANEL COVER ASSY, MFC8880DN FOR UK/FRA/BEL/NLD/GUL/EEU
(
ENGLISH
)
2 LS7640001 1 PANEL COVER ASSY, MFC8890DW FOR UK/FRA/BEL/NLD
(
ENGLISH
)
2 LS7609001 1 PANEL COVER ASSY, DCP8085DN FOR FRA/BEL/NLD/CHE
(
FRENCH
)
2 LS7564001 1 PANEL COVER ASSY, MFC8880DN FOR FRA/BEL/NLD/CHE
(
FRENCH
)
2 LS7641001 1 PANEL COVER ASSY, MFC8890DW FOR FRA/BEL/NLD/CHE
(
FRENCH
)
2 LS7610001 1 PANEL COVER ASSY, DCP8085DN FOR FRA/BEL/NLD
(
DUTCH
)
2 LS7565001 1 PANEL COVER ASSY, MFC8880DN FOR FRA/BEL/NLD
(
DUTCH
)
2 LS7642001 1 PANEL COVER ASSY, MFC8890DW FOR FRA/BEL/NLD
(
DUTCH
)
2 LS7604001 1 PANEL COVER ASSY, DCP8085DN FOR IT
A
2 LS7558001 1 PANEL COVER ASSY, MFC8880DN FOR IT
A
2 LX2211001 1 PANEL COVER ASSY, MFC8881DNHY FOR IT
A
2 LS7638001 1 PANEL COVER ASSY, MFC8890DW FOR ITA
2 LX2026001 1 PANEL COVER ASSY, DCP8085DN FOR CHN
2 LS7920001 1 PANEL COVER ASSY, MFC8880DN FOR CHN
2 LS7994001 1 PANEL COVER ASSY, MFC8880DN FOR PHL/ASA/IND/ARL/N
Z
2 LS7939001 1 PANEL COVER ASSY, DCP8085DN FOR TU
R
2 LS7981001 1 PANEL COVER ASSY, MFC8880DN FOR TU
R
2 LS7930001 1 PANEL COVER ASSY, DCP8080DN FOR ARG
2 LS7952001 1 PANEL COVER ASSY, MFC8480DN FOR ARG/CH
L
2 LX2008001 1 PANEL COVER ASSY, MFC8890DW FOR ARG/CHL
2 LS7983001 1 PANEL COVER ASSY, MFC8880DN FOR PO
L
2 LX2084001 1 PANEL COVER ASSY, DCP8080DN FOR BR
A
2 LX2074001 1 PANEL COVER ASSY, DCP8085DN FOR BR
A
2 LX2077001 1 PANEL COVER ASSY, MFC8480DN FOR BR
A
2 LX2080001 1 PANEL COVER ASSY, MFC8890DW FOR BR
A
2 LX2054001 1 PANEL COVER ASSY, MFC8880DN FOR KO
R
2 LS7943001 1 PANEL COVER ASSY, DCP8085DN FOR RUS
2 LS7990001 1 PANEL COVER ASSY, MFC8880DN FOR RU
S
2 LS7664001 1 PANEL COVER ASSY, MFC8880DN FOR PN
D
2 LS7682001 1 PANEL COVER ASSY, MFC8890DW FOR PND
2 LS7614001 1 PANEL COVER ASSY, DCP8085DN FOR ARG/CHL/IBR
(
SPANISH
)
2 LS7566001 1 PANEL COVER ASSY, MFC8880DN FOR IBR
(
SPANISH
)
2 LS7645001 1 PANEL COVER ASSY, MFC8890DW FOR IBR
(
SPANISH
)
2 LS7615001 1 PANEL COVER ASSY, DCP8085DN FOR IBR
(
PORTUGUESE
)
2 LS7567001 1 PANEL COVER ASSY, MFC8880DN FOR IBR
(
PORTUGUESE
)
2 LS7646001 1 PANEL COVER ASSY, MFC8890DW FOR IBR
(
PORTUGUESE
)
2 LX2051001 1 PANEL COVER ASSY, DCP8085DN FOR EEU
2-1 LF9717002 1 ADDRESS LABEL, MFC8480DN/MFC8680DN/MFC8880DN/
MFC8881DNHY/MFC8890DW EXCEPT FOR CHN
2-1 LP263700
3
1
A
DDRESS LABEL, MFC8880DN FOR CHN
2-1 LP218900
2
1
A
DDRESS LABEL, MFC8880DN/MFC8890DW FOR IB
R
3 08741121
6
4 TAPTITE CUP B M4X12
8C5D11/8C5D16/8C5D41/
8C5D51/8C5D56/8C5D61
DCP8080DN/DCP8085DN/MFC8480DN/
MFC8680DN/MFC8880DN/MFC8881DNHY/MFC8890DW
- 24 -

Brother MFC-8480DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	32 ppm
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	32 cpm
Faxing	Mono faxing
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Power supply type	AC
Weight (imperial)	40.3 lbs
Dimensions (WxDxH)	530.8 x 449.5 x 474.9 mm
Power requirements	110 - 240V, 50/60 Hz
All-in-one functions	Copy, Fax, Scan
Standard media sizes	2.75'' - 8.5\
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows OS Mac OS
Package dimensions (W x D x H)	24.7 x 22.3 x 22.6 \
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	30 dB
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, LLMNR, LPR/LPD, IPP/IPPS, FTP, HTTP/HTTPS, SSL/TLS, TFTP, SMTP, APOP, POP, SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD, CIFS, SNTP, NDP, RA, DNS, mDNS, ICMPv6
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18 W
Power consumption (average operating)	680 W
Package weight	21645 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	30000 pages per month
Recommended duty cycle	3500 pages per month
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	20 - 80 %
