Home > Network > Network Management Software and Utilities > Learn about Network Management
Software and Utilities
Learn about Network Management Software and Utilities
Web Based Management
Web Based Management is a utility that uses a standard web browser to manage your machine using the Hyper
Text Transfer Protocol (HTTP) or Hyper Text Transfer Protocol over Secure Socket Layer (HTTPS). Type your
machine's IP address into your web browser to access and change your print server settings.
BRAdmin Light (Windows
®
)
BRAdmin Light is a utility for the initial setup of Brother network-connected devices. This utility can search for
Brother products on your network, view the status and configure the basic network settings, such as IP address.
Go to your model's Downloads page on the Brother Solutions Center at
support.brother.com to download
BRAdmin Light.
If using Windows
®
Firewall, or the firewall function of an anti-spyware or antivirus application,
temporarily disable them. When you are sure you can print, configure the software settings following the
instructions.
BRAdmin Professional 3 (Windows
®
)
BRAdmin Professional 3 is a utility for more advanced management of network-connected Brother devices. This
utility can search for Brother products on your network and view the device status from an easy-to-read
Windows
®
Explorer-style screen that changes colour to identify the status of each device. You can configure
network and device settings, and update device firmware from a Windows
®
computer on your LAN. BRAdmin
Professional 3 can also log activity of Brother devices on your network and export the log data.
Go to your model's Downloads page on the Brother Solutions Center at support.brother.com to
download the latest version of Brother's BRAdmin Professional 3 utility.
Node name: The node name appears in the current BRAdmin Professional 3 window. The default node
name is "BRNxxxxxxxxxxxx" for a wired network or "BRWxxxxxxxxxxxx" for a wireless network (where
"xxxxxxxxxxxx" is your machine's MAC Address / Ethernet address).
If using Windows
®
Firewall, or the firewall function of an anti-spyware or antivirus application,
temporarily disable them. When you are sure you can print, configure the software settings following the
instructions.
Remote Setup (Windows
®
and Macintosh)
Remote Setup is a program for configuring many machine and network settings from either a Windows
®
or a
Macintosh application. When you start this application, the settings on your machine are automatically
downloaded to your computer and displayed on your computer screen. If you change the settings, you can
upload them directly to the machine.
This utility can be used with either a USB or a network connection.
Related Information
Network Management Software and Utilities
399

Table of Contents

Other manuals for Brother MFC-J6530DW

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Brother MFC-J6530DW and is the answer not in the manual?

Brother MFC-J6530DW Specifications

General IconGeneral
N-up printing2, 4, 9, 16, 25
Duplex printingYes
Print technologyInkjet
Maximum resolution1200 x 4800 DPI
Print speed (ISO/IEC 24734) mono22 ipm
Print speed (ISO/IEC 24734) color20 ipm
Time to first page (black, normal)6 s
Duplex print speed (ISO/IEC 24734) mono12 ipm
Duplex print speed (ISO/IEC 24734) color11 ipm
Print speed (black, normal quality, A4/US Letter)35 ppm
Print speed (color, normal quality, A4/US Letter)27 ppm
Copier resize25 - 400 %
Duplex copyingNo
Maximum copy resolution600 x 600 DPI
Maximum number of copies99 copies
N-in-1 copy function (N=)2, 4
Copy speed (black, normal quality, A4)12 cpm
Copy speed (color, normal quality, A4)9 cpm
Scan toE-mail, E-mail Server, FTP, File, Image, OCR, USB
Scan driversICA, SANE, TWAIN, WIA
Scanner typeFlatbed & ADF scanner
Grayscale levels256
Input color depth48 bit
Output color depth24 bit
Scan speed (black)8 inch/min
Maximum scan resolution19200 x 19200 DPI
Duplex scan speed (color)18 ppm
Optical scanning resolution1200 x 2400 DPI
FaxingMono faxing
Fax memory200 pages
Modem speed33.6 Kbit/s
Fax speed dialing (max numbers)100
DisplayLCD
Control typeTouch
Product colorBlack
Display diagonal2.67 \
Market positioningBusiness
Photo paper sizes9x13, 10x15, 13x18 cm
Custom media width105 - 297 mm
Custom media length148 - 431.8 mm
Duplex media weight60 - 120 g/m²
Paper tray media typesEnvelopes, Photo paper, Recycled paper
Paper tray media weight64 - 120 g/m²
Non-ISO print media sizesFolio
ISO A-series sizes (A0...A9)A3, A4, A5, A6
ISO C-series sizes (C0...C9)C5
Photo paper sizes (imperial)13x18 \
Maximum ISO A-series paper sizeA3
Auto Document Feeder (ADF) media weight64 - 90 g/m²
Internal memory128 MB
Sound power level (standby)50 dB
Standard interfacesEthernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity1
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security featuresAPOP, SMTP-AUTH, SSL/TLS (IPPS, HTTPS, FTPS, SMTP, POP3, IMAP4), SNMP v3 802.1x (EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS), Kerberos
Cabling technology10/100Base-T(X)
Security algorithms64-bit WEP, 128-bit WEP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPA2-TKIP
Ethernet LAN data rates10, 100 Mbit/s
Online services supportedDropbox, Evernote, Facebook, Flickr, Google Drive, OneDrive, OneNote
Mobile printing technologiesApple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS resolver, mDNS, LLMNR responder, LPR/LPD, custom Raw Port/Port9100, IPP, FTP/FTPs client FTP server, SNMPv1/v2c/v3, TFTP server, SMTP client, ICMP, web services (Print/Scan), CIFS client, SNTP client, POP3, LDAP, IMAP4, HTTP server
Supported network protocols (IPv6)NDP, RA, mDNS, LLMNR responder, DNS resolver, LPR/LPD, custom raw port/Port9100, IPP, FTP/FTPs client FTP , SNMPv1/v2c/v3 , TFTP server, web services (print/scan), SMTP client, POP3*, CIFS client, SNTP client, LDAP, IMAP4*, ICMPv6, HTTP serve
Package depth568 mm
Package width681 mm
Package height430 mm
Package weight23900 g
Sustainability certificatesBlue Angel, ENERGY STAR
Power consumption (off)0.4 W
Power consumption (sleep)1.6 W
Power consumption (standby)6 W
Power consumption (average operating)27 W
Cartridge typeLC3217
Paper input typePaper tray
Total input capacity250 sheets
Total output capacity100 sheets
Auto document feeder (ADF) input capacity50 sheets
Maximum duty cycle30000 pages per month
Recommended duty cycle250 - 2000 pages per month
Page description languages-
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.9 Mavericks
Mobile operating systems supportedAndroid
Server operating systems supportedWindows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic
Bundled softwareBrother Control Center Version 4, Nuance PaperPort Version 14
Harmonized System (HS) code84433100
Weight and Dimensions IconWeight and Dimensions
Depth477 mm
Width575 mm
Height305 mm
