Brother MFC-J6930DW Service Manual

Confidential
2-18
Error Message State
Error
Code
Reference
Jam Front/Rear
Jam Front
Jam Rear
Jam MP Tray
Jam Front/MP Tray
Jam Tray2
Jam Tray3
Paper Jam
Repeat Jam (XX)
Repetitive Paper Jams
Paper jam during duplex-printing
The recording papers are fed in reverse on the
platen when switchback drive is started, triggering
switchback sensor as paper feeding condition.
0D00
2-25
Defective during duplex-printing
Switchback sensor detects paper feed condition at
out of specified timing during switchback.
0E00 2-25
Defective during duplex-printing
Registration sensor detects paper feed condition
at out of specified timing during switchback.
1300 2-26
Paper jam during duplex ejecting
Recording paper is not able to be ejected since it
is longer than 840 mm when ejecting the paper.
1500 2-26
Paper jam during duplex-printing
Registration sensor does not detect paper feed
within specified pulse numbers in the second side
paper re-feed.
1800 2-27
Carriage cannot detect origin.
Detected by the CR encoder sensor.
3100 2-34
Abnormal stop of head/carriage unit being driven
Caused by paper jam when ink is not discharging
3800 2-35
Abnormal stop of head/carriage unit being driven
Caused by paper jam when ink is discharging
3C00 2-36
Paper jam
Paper width sensor cannot detect leading edge or
width of recording papers.
8200 2-47
Paper jam
Registration sensor stays in paper feeding state
even after completion of paper ejection action.
8400 2-47
Paper jam
Switchback sensor stays in paper feeding state
even after completion of paper ejection action.
8700 2-48
Paper jam
Switchback sensor cannot detect paper feeding
state even papers are fed during printing.
8800 2-48
Low Temperature It was detected that the head temperature is the
specified value or less.
4300 2-38
It was detected that the machine temperature is
the specified value or less.
4000 2-37
Machine Error SDAA communication failure D200 2-54
Media is Full The memory in the media slot is full, or there are
999 or more files.
No Caller ID There is no caller ID information.
