Brother MFC-J825DW Quick Setup Guide

20
Windows
®
Wired Network
For wired network interface users
(Windows
®
XP Home/XP Professional/Windows Vista
®
/Windows
®
7)
16
Before you install
Make sure that your computer is ON and you are
logged on with Administrator rights.
17
Connect the network
cable
a Using both hands, use the plastic tabs on both
sides of the machine to lift the scanner cover
until it locks securely into the open position.
b You will find the LAN socket marked with a
symbol inside the machine on the left as shown
below. Remove the protective cap and connect
the network cable to the LAN socket.
c Carefully guide the network cable into the cable
channel and out the back of the machine.
Connect the cable to your network.
IMPORTANT
If there are any programs running, close them.
Note
• The screens may differ depending on your
operating system.
• The CD-ROM includes ScanSoft™
PaperPort™12SE. This software supports
Windows
®
XP Home (SP3 or greater), XP
Professional x32 Edition (SP3 or greater), XP
Professional x64 Edition (SP2 or greater),
Windows Vista
®
(SP2 or greater) and
Windows
®
7. Update to the latest Windows
®
Service Pack before installing MFL-Pro Suite.
IMPORTANT
Make sure that the cable does not restrict the
cover from closing, or an error may occur.
Note
If both the USB and the LAN cables are being
used, guide both cables through the cable
channel with one on top of the other.
USB

Brother MFC-J825DW Specifications

General

PictBridge	Yes
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	copy, fax, print, scan
Print technology	Inkjet
Maximum resolution	1200 x 6000 DPI
Duplex printing mode	Auto
Print speed (black, normal quality, A4/US Letter)	35 ppm
Print speed (color, normal quality, A4/US Letter)	27 ppm
Digital sender	No
Maximum duty cycle	- pages per month
Number of print cartridges	4
Page description languages	GDI
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 1200 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (color, normal)	24 s
Copy speed (black, normal quality, A4)	23 cpm
Copy speed (color, normal quality, A4)	20 cpm
Scan to	E-mail, File, Image, OCR, USB
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Input color depth	36 bit
Maximum scan area	216 x 355 mm
Output color depth	24 bit
Image formats supported	BMP, JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Optical scanning resolution	2400 x 2400 DPI
Faxing	Color faxing
Fax memory	400 pages
Modem speed	33.6 Kbit/s
Fax coding methods	MH, MMR (Fax coding method), MR
Fax resolution (black)	203 x 392 DPI
Paper input type	Cassette
Total input capacity	100 sheets
Total output capacity	50 sheets
Auto document feeder (ADF) input capacity	15 sheets
Maximum print size	216 x 297 mm
Paper tray media types	Glossy paper, Photo paper, Plain paper, Transparencies
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
Photo paper sizes (imperial)	4x6, 5x7, 5x8, 8x10, 8.5x11 \
Borderless printing media sizes	4x6, 5x7, A4, A6, Letter
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight (imperial)	64 - 90 lbs
Display	LCD
Control type	Touch
Product color	Black
Market positioning	Home & office
Standard interfaces	Ethernet, USB 2.0, Wireless LAN
USB 2.0 ports quantity	1
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, WPA-PSK, WPA-TKIP, WPA2-PSK, WPS
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Processor family	RISC
Compatible memory cards	Memory Stick (MS), MMC, MS PRO, SD, SDHC, SDXC
Power consumption (off)	2.5 W
Power consumption (standby)	6.5 W
Power consumption (average operating)	24 W
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.7 Lion
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Bundled software	Brother MFL-Pro Suite\\r Brother ControlCentre4 (Win)\\r Nuance® Paperport® 12 SE + OCR (Win)\\r Reallusion® FaceFilter Studio (Win8)\\r Brother ControlCentre2 (Mac)\\r NewSoft® Presto!® PageManager9 (Mac)
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	378 mm
Width	405 mm
Height	180 mm
