Brother MFC-J880DW User Manual

Home > Network > Additional Methods of Configuring Your Brother Machine for a Wireless Network > Use
Wi-Fi Direct
®
> Configure Your Wi-Fi Direct Network > Configure Your Wi-Fi Direct Network Using the One-
Push Method
Configure Your Wi-Fi Direct Network Using the One-Push Method
>> MFC-J460DW/MFC-J480DW/MFC-J485DW
>> MFC-J680DW/MFC-J880DW/MFC-J885DW
MFC-J460DW/MFC-J480DW/MFC-J485DW
If your mobile device supports Wi-Fi Direct, follow these steps to configure a Wi-Fi Direct network:
When the machine receives the Wi-Fi Direct request from your mobile device, the message [Wi-Fi
Direct connection request received.] will appear on the LCD. Press OK to connect.
1. Press Settings.
2. Press a or b to select the following:
a. Select [Network]. Press OK.
b. Select [Wi-Fi Direct]. Press OK.
c. Select [Push Button]. Press OK.
3. When [Wi-Fi Direct On? Yes ⇒ Press 1 No ⇒ Press 2] appears, press 1 to accept. To cancel,
press 2.
4. Activate your mobile device's WPS PIN configuration method (see your mobile device's user's guide for
instructions) when [Activate Wi-Fi Direct on other device. Then press OK.] appears. Press
OK on your Brother machine. This will start the Wi-Fi Direct setup.
5. Do one of the following:
• When your Brother machine is the G/O (Group Owner), connect your mobile device to the machine
directly.
• When your Brother machine is not the G/O, it will display available device names with which to configure
a Wi-Fi Direct network. Select the mobile device to which you want to connect and press OK. Search for
available devices again by selecting [Rescan].
6. If your mobile device connects successfully, the machine displays [Connected]. You have completed the
Wi-Fi Direct network setup. For more information on printing from or scanning to your mobile device,
download the Mobile Print/Scan Guide for Brother iPrint&Scan or the AirPrint Guide from your model's
Manuals page on the Brother Solutions Center at
http://support.brother.com.
MFC-J680DW/MFC-J880DW/MFC-J885DW
If your mobile device supports Wi-Fi Direct, follow these steps to configure a Wi-Fi Direct network:
When the machine receives the Wi-Fi Direct request from your mobile device, the message [Wi-Fi
Direct connection request received. Press [OK] to connect.] will appear on the LCD.
Press [OK] to connect.
1. Press [Settings] > [All Settings] > [Network] > [Wi-Fi Direct] > [Push Button].
2. When [Wi-Fi Direct On?] appears, press [On] to accept. To cancel, press [Off].
3. Activate Wi-Fi Direct on your mobile device (see your mobile device's user's guide for instructions) when
[Activate Wi-Fi Direct on other device. Then Press [OK].] appears. Press [OK] on your
Brother machine. This will start the Wi-Fi Direct setup.
4. Do one of the following:
• When your Brother machine is the G/O (Group Owner), connect your mobile device to the machine
directly.
398

Brother MFC-J880DW Specifications

General

Display	LCD
Control type	Touch
Product color	Black
Display diagonal	2.7 \
Market positioning	Home & office
Mac operating systems supported	Mac OS X 10.8 Mountain Lion, Mac OS X 10.0 Cheetah, Mac OS X 10.9 Mavericks
Other operating systems supported	Android, iOS, Windows Phone
Server operating systems supported	Windows Server 2012 R2 x64, Windows Server 2003, Windows Server 2008 R2 x64, Windows Server 2012 x64, Windows Server 2008 x64, Windows Server 2003 x64, Windows Server 2008
Windows operating systems supported	Windows 7 Enterprise, Windows 8, Windows Vista Home Premium, Windows 10 Education, Windows 7 Enterprise x64, Windows 8 Enterprise, Windows Vista Home Premium x64, Windows 10 Education x64, Windows 7 Home Basic, Windows 8 Enterprise x64, Windows Vista Ultimate, Windows 10 Enterprise, Windows 7 Home Basic x64, Windows 8 Pro, Windows Vista Ultimate x64, Windows 10 Enterprise x64, Windows 7 Home Premium, Windows 8 Pro x64, Windows XP Home, Windows 10 Home, Windows 7 Home Premium x64, Windows 8 x64, Windows XP Home x64, Windows 10 Home x64, Windows 7 Professional, Windows 8.1, Windows Vista Business, Windows XP Professional, Windows 10 Pro, Windows 7 Professional x64, Windows 8.1 Enterprise, Windows Vista Business x64, Windows XP Professional x64, Windows 10 Pro x64, Windows 7 Starter, Windows 8.1 Enterprise x64, Windows Vista Enterprise, Windows 7 Starter x64, Windows 8.1 Pro, Windows Vista Enterprise x64, Windows 7 Ultimate, Windows 8.1 Pro x64, Windows Vista Home Basic, Windows 7 Ultimate x64, Windows 8.1 x64, Windows Vista Home Basic x64
Noise level	50 dB
Wi-Fi standards	802.11g, 802.11b, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	WPA2-AES, APOP, SSID, 64-bit WEP, WPA2-PSK, 128-bit WEP, WPS, WPA-AES, SMTP-AUTH, WPA-PSK, WPA-TKIP
Ethernet LAN data rates	10, 100 Mbit/s
Online services supported	Box, Facebook, OneDrive, Dropbox, Flickr, OneNote, Evernote, Google Drive, Picasa
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Mopria Print Service, Google Cloud Print
Direct printing	-
Standard interfaces	NFC, Ethernet, USB 2.0, Wireless LAN
Compatible memory cards	MMC, MMC Mobile, MiniSD, MMC+, MiniSDHC, MS Duo, MS Micro (M2), MS PRO, SD, MS PRO Duo, MicroSD (TransFlash), SDHC, MicroSDHC, SDXC
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 1200 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	6 cpm
Envelopes sizes	10, DL, C5, Monarch
Photo paper sizes	10x15, 13x18 cm
Paper tray media types	Envelopes, Glossy paper, Plain paper, Coated paper, Recycled paper
Non-ISO print media sizes	2L, Executive (184 x 267mm), Letter (media size), Index card, L
ISO A-series sizes (A0...A9)	A5, A6, A4
ISO C-series sizes (C0...C9)	C5
Maximum ISO A-series paper size	A4
Digital sender	No
Printing colors	Black, Cyan, Magenta, Yellow
Number of print cartridges	4
Sustainability certificates	Nordic Swan Ecolabel, ENERGY STAR
Scan to	Image, Fax, Memory Card, USB, E-mail, File, OCR
Scan drivers	ICA, TWAIN, WIA
Scanner type	ADF scanner
Grayscale levels	256
Input color depth	30 bit
Maximum scan area	A4 (210 x 297) mm
Output color depth	24 bit
Image formats supported	BMP, JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Optical scanning resolution	1200 x 2400 DPI
Print technology	Inkjet
Maximum resolution	6000 x 1200 DPI
Duplex printing mode	Auto
Print speed (ISO/IEC 24734) mono	12 ipm
Print speed (ISO/IEC 24734) color	10 ipm
Print speed (black, normal quality, A4/US Letter)	27 ppm
Print speed (color, normal quality, A4/US Letter)	23 ppm
Bundled software	Brother Control Center 4 Nuance PaperPort 14 SE Brother Control Center 2 Pagemanager 9
Faxing	Color faxing
Fax memory	200 pages
Modem speed	14.4 Kbit/s
Fax resolution (black)	203 x 203 DPI
Package depth	249 mm
Package width	477 mm
Package height	456 mm
Package weight	11200 g
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.2 W
Power consumption (standby)	3.5 W
Power consumption (average operating)	19 W
Paper input type	Paper tray
Total input capacity	100 sheets
Total output capacity	50 sheets
Auto document feeder (ADF) input capacity	20 sheets
Storage temperature (T-T)	20 - 33 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	341 mm
Width	400 mm
Height	172 mm
