Brother MFC-L6700DW Service Manual

2-18
Confidential
Error
codes
Description
Refer
to:
Error
codes
Description
Refer
to:
8601 ― 8903
The back cover/duplex tray sensor
detected that the cover was open
when duplex printing is started.
(Before registering printing data to
engine)
2-65
8602 ― 8904
The back cover/duplex tray sensor
detected that the cover was open
during duplex printing. (After
registering printing data to engine)
2-65
8603 ― 8A01
The registration rear sensor detected
that the paper fed was smaller or
larger than the specified size in duplex
printing mode.
2-65
8604 ― 8A02 ―
8701 ― 8B01
Detected that the TT was not turned
ON.
2-66
8702
Machine stack sensor detected the
ejected paper full state at the start of
printing.
2-64
8C00 ―
8703 ― 8D01 ―
8708 ― 8D02 ―
8709 ― 8E01 ―
870A ― 8E02
Detected that the size of paper set in
the paper tray was over 10 mm shorter
than letter size during receiving fax
data or printing a list or report.
2-66
870B ― 8F01 ―
870C ― 8F02 ―
870D ― 8F03 ―
870E ― 9001
When printing from the MP tray, the
size of paper set in the MP tray does
not match the size specified by the
driver.
2-67
870F ― 9002
When printing from the paper tray 1,
the size of paper set in the paper tray
1 does not match the size specified by
the driver.
2-67
8801 ― 9003
When printing from the paper tray 2,
the size of paper set in the paper tray
2 does not match the size specified by
the driver.
2-67
8802 ― 9004
When printing from the paper tray 3,
the size of paper set in the paper tray
3 does not match the size specified by
the driver.
2-67
8808 ― 9005
When printing from the paper tray 4,
the size of paper set in the paper tray
4 does not match the size specified by
the driver.
2-67
8809 ― 9006
When printing from the paper tray 5,
the size of paper set in the paper tray
5 does not match the size specified by
the driver.
2-67
880A ― 9102 ―
8901 ― 9103 ―
8902 ― 9104 ―

Brother MFC-L6700DW Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	48 ppm
Digital sender	-
Maximum duty cycle	100000 pages per month
Recommended duty cycle	0 - 5000 pages per month
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6, PDF 1.7
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A4)	48 cpm
Scan to	E-mail, FTP, File, Image, OCR, USB
Scan drivers	ICA, ISIS, SANE, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Scan speed (black)	28 ppm
Scan speed (color)	20 ppm
Image formats supported	BMP, JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Duplex scan speed (black)	56 ppm
Duplex scan speed (color)	34 ppm
Document formats supported	DOCX, PDF, PPTX, XML, XPS
Email protocols	APOP, IMAP4, POP3
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, APOP, EAP-FAST, SMTP-AUTH, SSL/TLS, WPA-PSK, WPA2-PSK
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Online services supported	Dropbox, Evernote, Google Drive, OneDrive
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, POP3, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Print/Scan), SNTP Client, LDAP, IMAP4
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, POP3, SMTP Client, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c, HTTP/HTTPS server, TFTP client and server, ICMPv6, SNTP Client, LDAP, Web Services (Print/Scan), IMAP4
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax transmission speed	2.5 sec/page
Total input capacity	520 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	70 sheets
Envelopes sizes	6 3/4, 7 3/4, 9, 10
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
ISO A-series sizes (A0...A9)	A4, A5, A6
Duplex media weight (imperial)	17 - 24 lbs
Multi-purpose tray media types	Bond paper
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	16 - 32 lbs
Multi-Purpose Tray media weight (imperial)	16 - 53 lbs
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	4.85 \
Market positioning	Business
Internal memory	512 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	55 dB
Sustainability certificates	ENERGY STAR
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	36 W
Power consumption (sleep)	1.8 W
Power consumption (average operating)	680 W
Operating relative humidity (H-H)	20 - 80 %
Package depth	525.78 mm
Package width	599.44 mm
Package height	657.86 mm
Package weight	22089.95 g

Weight and Dimensions

Width	495.3 mm
