Brother MFC-L6700DW Service Manual

2-19
Confidential
Error
codes
Description
Refer
to:
Error
codes
Description
Refer
to:
9105 ― 9502 ―
9200 ― 9503 ―
9201
When printing from the MP tray, paper
type setting in the machine does not
match the setting in the driver.
2-68 9504 ―
9202
When printing from the paper tray 1,
paper type setting in the machine
does not match the setting in the
driver.
2-68
9505 ―
9203
When printing from the paper tray 2,
paper type setting in the machine
does not match the setting in the
driver.
2-68
9601 ―
9204
When printing from the paper tray 3,
paper type setting in the machine
does not match the setting in the
driver.
2-68
9608 ―
9205
When printing from the paper tray 4,
paper type setting in the machine
does not match the setting in the
driver.
2-68 9701
A tray set to duplex printing-
incompatible size was specified in
duplex printing.
2-72
9206
When printing from the paper tray 5,
paper type setting in the machine
does not match the setting in the
driver.
2-68 9702
When printing from paper tray 1, a
paper size not supported for paper
tray 1 was specified from the driver.
2-72
9301
When printing from the MP tray, the
MP paper empty sensor detected that
there was no paper set in the MP tray.
2-69 9703
When printing from paper tray 2, a
paper size not supported for paper
tray 2 was specified from the driver.
2-72
9302
When printing from paper tray 1, the
T1 paper empty sensor or the T1
paper feed sensor detected that there
was no paper set in paper tray 1.
2-69 9704
When printing from paper tray 3, a
paper size not supported for paper
tray 3 was specified from the driver.
2-72
9303
When printing from paper tray 2, the
T2(LT or TT) paper empty sensor
detected that there was no paper set
in paper tray 2.
2-69 9705
When printing from paper tray 4, a
paper size not supported for paper
tray 4 was specified from the driver.
2-72
9304
When printing from paper tray 3, the
T3(LT or TT) paper empty sensor
detected that there was no paper set
in paper tray 3.
2-69 9706
When printing from paper tray 5, a
paper size not supported for paper
tray 5 was specified from the driver.
2-72
9305
When printing from paper tray 4, the
T4(LT or TT) paper empty sensor
detected that there was no paper set
in paper tray 4.
2-69
9801 ―
9306
When printing from paper tray 5, the
T5TT paper empty sensor detected
that there was no paper set in paper
tray 5.
2-69
9802 ―
9309
Detected that there was no paper set
in all trays when TrayAuto was
selected for printing.
2-70 9803 ―
930A
Paper ran out during Fax / List
continuous printing.
2-71
9804 ―
9400
Firmware version of the main PCB is
older than that of the TT and LT.
2-71
9901 ―
9501 ― 9902 ―

Brother MFC-L6700DW Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	48 ppm
Digital sender	-
Maximum duty cycle	100000 pages per month
Recommended duty cycle	0 - 5000 pages per month
Page description languages	BR-Script 3, Epson FX, IBM ProPrinter, PCL 6, PDF 1.7
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
N-in-1 copy function (N=)	2, 4
Copy speed (black, normal quality, A4)	48 cpm
Scan to	E-mail, FTP, File, Image, OCR, USB
Scan drivers	ICA, ISIS, SANE, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Scan speed (black)	28 ppm
Scan speed (color)	20 ppm
Image formats supported	BMP, JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Duplex scan speed (black)	56 ppm
Duplex scan speed (color)	34 ppm
Document formats supported	DOCX, PDF, PPTX, XML, XPS
Email protocols	APOP, IMAP4, POP3
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, 802.1x RADIUS, APOP, EAP-FAST, SMTP-AUTH, SSL/TLS, WPA-PSK, WPA2-PSK
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Online services supported	Dropbox, Evernote, Google Drive, OneDrive
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print, Mopria Print Service
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA(Auto IP), WINS/NetBIOS name resolution, DNS Resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, POP3, SMTP Client, IPP/IPPS, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c/v3, HTTP/HTTPS server, TFTP client and server, ICMP, Web Services (Print/Scan), SNTP Client, LDAP, IMAP4
Supported network protocols (IPv6)	NDP, RA, DNS resolver, mDNS, LLMNR responder, LPR/LPD, Custom Raw Port/Port9100, IPP/IPPS, POP3, SMTP Client, FTP Client and Server, CIFS Client, TELNET Server, SNMPv1/v2c, HTTP/HTTPS server, TFTP client and server, ICMPv6, SNTP Client, LDAP, Web Services (Print/Scan), IMAP4
Faxing	Mono faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax transmission speed	2.5 sec/page
Total input capacity	520 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	50 sheets
Auto document feeder (ADF) input capacity	70 sheets
Envelopes sizes	6 3/4, 7 3/4, 9, 10
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper
ISO A-series sizes (A0...A9)	A4, A5, A6
Duplex media weight (imperial)	17 - 24 lbs
Multi-purpose tray media types	Bond paper
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	16 - 32 lbs
Multi-Purpose Tray media weight (imperial)	16 - 53 lbs
Display	LCD
Control type	Touch
Product color	Black
Display diagonal	4.85 \
Market positioning	Business
Internal memory	512 MB
Sound power level (standby)	35 dB
Sound pressure level (printing)	55 dB
Sustainability certificates	ENERGY STAR
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (ready)	36 W
Power consumption (sleep)	1.8 W
Power consumption (average operating)	680 W
Operating relative humidity (H-H)	20 - 80 %
Package depth	525.78 mm
Package width	599.44 mm
Package height	657.86 mm
Package weight	22089.95 g

Weight and Dimensions

Width	495.3 mm
