Home > Security > Network Security Features > Manage Your Network Machine Securely Using
IPsec > Configure IPsec Using Web Based Management
Configure IPsec Using Web Based Management
The IPsec connection conditions are comprised of two Template types: Address and IPsec. You can configure
up to 10 connection conditions.
1. Start your web browser.
2. Type "http://machine's IP address" in your browser's address bar (where "machine's IP address" is the
machine's IP address).
For example:
http://192.168.1.2
3. No password is required by default. Type a password if you have set one, and then click
.
4. Click the Network tab.
5. Click the Security tab.
6. Click the IPsec menu in the left navigation bar.
7. In the Status field, enable or disable IPsec.
8. Select Negotiation Mode for IKE Phase 1.
IKE is a protocol that is used to exchange encryption keys in order to carry out encrypted communication
using IPsec.
459
