1 . PRINT MECHANISM

REF.NO. CODE Q'TY DESCRIPTION REMARKS

1 LA8191001 1 CHASSIS 3600 ASSY R

2 LA8436001 1 TAPE FEED MOTOR ASSY

3 LA8984001 1 ROLLER HOLDER ASSY 3600 (SP) R

4 UT0895001 1 ROLLER HOLDER SHAFT

5 LA2071001 1 HEAD ASSY, KSH384 BW3 (SP) R

6 UT0901001 1 ROLLER HOLDER RELEASE SPRING

7 UT0239000 1 RELEASE LEVER

8 UT0240000 1 RELEASE ROD

9 UB5507000 1 RELEASE ROD ROLLER

10 UT1549001 1 RELEASE LEVER SPRING PRO

11 0A4300805 2 SCREW, PAN (S/P WASHER) M3X8

12 LA8986001 1 HALF CUTTER CHASSIS ASSY (SP) R

13 000300615 10 SCREW, BIND M3X6

14 LA8239001 1 EJECT MOTOR ASSY R

15 LA3057000 1 DOUBLE GEAR 1

16 LA8553001 1 EJECT IDLE GEAR

17 LA8440001 1 EJECT GEAR

18 LA8241001 1 EJECT RUBBER

19 LA8242001 1 EJECT ROLLER SHAFT

20 LA8243001 1 TAPE GUIDE

21 LA8554001 1 EJECT SHAFT SPRING

22 LA8244001 1 HC MOTOR HOLDER

23 LA8555001 1 HC SUPPORT PLATE

24 LA8245001 1 CARRIAGE MOTOR 3600 ASSY R

25 LA8246001 1 TAPE CONTROL MOTOR 3600 ASSY R

26 LA8247001 1 AV SENSOR ACTUATOR

27 LA8248001 1 AV SENSOR SPRING

28 UT0855001 1 SCREW, PAN M1.7X6

29 000020405 4 SCREW, BIND M2X4

30 085210415 1 TAPTITE, BIND B M2X4

31 060260516 4 SCREW, BIND M2.6X5

32 U62189000 1 PLATEN PROTECT PAD

33 048025346 2 RETAINING RING, E2.5

34 048015346 1 RETAINING RING, E1.5

35 LA8420001 3 SCREW, PAN 1.7X3

MODEL PT-9600 8V2-711-045

Brother P-touch PT-9600 Parts Reference List
