-4-

2 . COVERS PtPn020058

REF.NO. CODE Q'TY DESCRIPTION REMARKS

1 LA8249001 1 BODY COVER 9600 R

2 LA8252001 1 BOTTOM COVER 9600 R

3 LA8253001 1 HANDLE 9600 R

4 U05810001 2 HANDLE SHAFT R

5 LA8254001 1 CASSETTE COVER 9600 R

6 LA8255001 1 CASSETTE PRESSER

7 LA8256001 2 CASSETTE PRESSER SPRING

8 LA8257001 1 TAPE PANEL 9600 US (USA/CAN) R

8 LA8312001 1 TAPE PANEL 9600 EC (EUROPE/ZAF/AUS) R, ADD

9 LA8258001 1 LCD PANEL 9600 US (USA/CAN) R

9 LA8338001 1 LCD PANEL 9600 GE (DEU/AUT) R

9 LA8313001 1 LCD PANEL 9600 UK (GBR/IRL/NLD/CHE/DNK/SWE/ITA/BEL/FIN/NOR/ESP/ZAF/AUS) R, ADD

9 LA8341001 1 LCD PANEL 9600 FR (FRA) R

10 LA7417001 1 NAVI DIAL 1850 GE (DEU/AUT) R

10 LA7432001 1 NAVI DIAL 1850 UK (GBR/IRL/NLD/CHE/DNK/SWE/ITA/BEL/FIN/NOR/ESP/ZAF/AUS) R, ADD

10 LA7436001 1 NAVI DIAL 1850 FR (FRA) R

11 LA8900001 1 EMBLEM 9600 (USA/CAN) R

12 LA8260001 1 BATTERY LID 9600 R

13 LA5753001 2 LOWER FOOT 2300

14 LA8354001 1 LOCK ARM

15 LA8262001 1 LOCK ARM RETURN SPRING

16 LA8263001 1 RELEASE BUTTON

17 UT1489001 1 RELEASE BUTTON RETURN SPRING

18 LA8308001 1 SHIELD PLATE D

19 LA8264001 1 SHEET A

20 085270817 14 TAPTITE, BIND B M2.6X8

21 085271017 12 TAPTITE, BIND B M2.6X10

22 LA8266001 1 CAUTION LABEL 9600 US (USA/CAN)

22 LA8335001 1 CAUTION LABEL 9600 EC (EUROPE/ZAF/AUS) ADD

23 LA5703001 1 FCC LABEL 2300 (USA/CAN)

23 LA4998001 1 C-TICK MARK (AUS) ADD

24 LA8267001 1 LIGHT PLATE ASSY 9600

25 LA8565001 2 CUSHION

26 LA8963000 1 CORE CUSHION (EUROPE/ZAF/AUS) ADD

27 LA8620001 1 MYLAR LABEL 3600 US (USA)

28 LA9349001 1 BRAKE PAD 3600

MODEL PT-9600 8V2-711-061
