3 . KEYBOARD PtPn020058

REF.NO. SYMBOL CODE Q'TY DESCRIPTION REMARKS

1-8 LA8654001 1 KB UNIT US (USA/CAN) R

1-8 LA8655001 1 KB UNIT GE (DEU/AUT) R

1-8 LA8656001 1 KB UNIT UK (GBR/IRL/NLD/CHE/DNK/SWE/ITA/FIN/NOR/ESP R

/ZAF)

1-8 LA8657001 1 KB UNIT FR (FRA) R

1-8 LA8658001 1 KB UNIT BG (BEL) R

1-8 LN0032001 1 KB UNIT AUS (AUS) ADD

1 LA8250001 1 BODY KB COVER 9600 US (USA/CAN)

1 LA8337001 1 BODY KB COVER 9600 GE (DEU/AUT)

1 LA8311001 1 BODY KB COVER 9600 UK (GBR/IRL/NLD/CHE/DNK/SWE/ITA ADD

/FIN/NOR/ESP/BEL/ZAF/AUS)

1 LA8340001 1 BODY KB COVER 9600 FR (FRA)

2 LA8176001 1 CONTACT RUBBER

3 LA8177001 1 FUNCTION RUBBER 9600 US (USA/CAN)

3 LA8178001 1 FUNCTION RUBBER 9600 GE (DEU/AUT)

3 LA8179001 1 FUNCTION RUBBER 9600 UK (GBR/IRL/NLD/CHE/DNK/SWE/ITA ADD

/FIN/NOR/ESP/BEL/ZAF/AUS)

3 LA8180001 1 FUNCTION RUBBER 9600 FR (FRA)

4 LA8187001 1 KEY D SP WIRE

5 LA8188001 1 KEY C RET WIRE

6 LA8189001 1 FIX PLATE

7 B55L137-1 LA8190001 1 PCB, B55L137

8 085270817 4 TAPTITE, BIND B M2.6X8

9 085270817 2 TAPTITE, BIND B M2.6X8 (USA/CAN)

9 085270817 5 TAPTITE, BIND B M2.6X8 (EUROPE/ZAF/AUS) ADD

10 B55L139-1 LA8305001 1 JOG PCB ASSY 9600 (EUROPE/ZAF/AUS) R, ADD

MODEL PT-9600 8V2-711-003

Brother P-touch PT-9600 Parts Reference List
