OUTBOARD INSTALLATION
LIFTING THE OUTBOARD
2
15–30 HP MODELS
Use an appropriate chain, at least 36 in ches (91
cm) long with a sna p hook, capable of lifting 500
lbs. (227 kg).
Remove upper motor cover.
Remove chain from lifting tool.
Remove lifting tool from outboard.
Attach chain to lift eye on back of engine block.
Carefully lift engine with hoist.
To avoid damage to the outboard,
lift the outboard in one smooth motion. DO
NOT allow the outboard to bounce.
A CAUTION
To avoid damage to the outboard, DO NOT
allow the outboard to fall unrestrained.
A WARNING
If the chain snap hooks are too large, the
cast in lift eye could break causing the out-
board to drop suddenly causing personal
injury and damaging the outboard.
1. Lift eye 007212
007213
