 Oil and Fuel
Outboards Without Remote Oil Tank
Fill to bottom of filler neck.
Outboards With Remote Oil Tank
Fill to “Max Fill Line.”
Remote Oil Tank
Fill to bottom of filler neck.
Filling the Oil Tank
Release the port and starboard engine cover
latches by turning each handle downward.
Pull up on the tilt handle to release the engine
cover seal on the engine cover.
Remove the engine cover to access the oil
tank.
1. Bottom of filler neck
C04-009054
1. Max fill line
C04-09084
1. Bottom of filler neck
C04-09055
1
MAX. FILL LINE LEVEL
1
1
002015
1. Tilt handle
002016
002017
1
