77
Specifications
40, 50, 60, Models
Displacement
52.7 cu. in. (864 cc)
Engine Type
In-line, 2 Cylinder, Two-Cycle, E-TEC
Full Throttle Operating Range
40 HP – 5000 to 6000 RPM
40 HO – 5500 to 6000 RPM
50 HP – 5500 to 6000 RPM
40 Jet / 60 HP – 5500 to 6000 RPM
Power
(1)
(1) Rated following the standards of ICOMIA 28.83, ISO 3046 and NMMA.
40 HP – 40 HP (29.42 kw) @ 5750 RPM
40 H.O. – 40 HP (29.42 kw) @ 5750 RPM
50 HP – 50 HP (36.77 kw) @ 5750 RPM
40 Jet / 60 HP – 60 HP (44.13 kw) @ 5750 RPM
Idle RPM in Neutral Gear
(2)
(2) Emission Control Information.
750 ± 50
Ignition Timing
(2)
Not Adjustable
Emission Control System: per
SAE J1930
(2)
ECM, E-TEC (Engine Control Module, E-TEC)
Fuel Requirements
(2)
87 Pump Posted AKI (90 RON) – Refer to Fuel
Requirements on page 21
Oil – Lubricant
– Capacity
TC-W3 NMMA-certified oil or Evinrude XD100 oil
– Refer to Oil Requirements on page 18
2.0 qt. (1.9 l)
Warning Signals
Controlled by the outboard’s EMM
Battery, Minimum
(3)
(3) Use a 800 CCA (1000 MCA) battery when operating in temperatures below 32°F (0°C).
640 CCA (800 MCA) 12 volt or
800 CCA (1000 MCA) 12 volt below 32°F (0°C)
Spark Plug
(2)
Refer to Parts Catalog or engine ECI Label
Fuses
P/N 967545 – Refer to Fuse on page 60
Fuel Filter (12 to 15 micron)
P/N 5007335 – In-line Replaceable
Battery Charging
25-Amp, Fully Regulated
Gearcase – Lubricant
(4)
– Capacity
(4) Use Evinrude HPF Pro Gearcase Lubricant for high performance outboards and commercial
applications. Evinrude HPF Pro Gearcase Lubricant delivers exceptional durability and reliability and
promotes long gearcase life in marine use.
Evinrude HPF–Pro
22 fl. oz. (650 ml)
Power Trim/Tilt – Fluid
– Capacity
Evinrude Power Trim & Tilt Fluid, P/N 775612
11.7 fl. oz. (345 ml)
Propeller
Refer to Propeller Selection on page 74
Weight
L Models – 240 lbs. (109 kg)
Sound at Driver’s Ear
(LpA) ICOMIA 39.94
76.8 dB(A)
Vibration at Tiller (arms) Less than 2.5 m/s
1
Transom Height L Models – (20 in. shaft) 19 1/2 to 20 in. (495 to 508 mm)
