40
INSTALLATION AND PREDELIVERY
BOAT RIGGING
Two outboards: One primary starting battery for each outboard; one isolated accessory battery
Two outboards: One primary starting battery for each outboard; two isolated accessory batteries
ACCESSORY
PRIMARY
#1
PRIMARY
#2
S
S
+
+
+
1
2
OFF
BOTH
1
2
OFF
BOTH
#1
#2
ACCESSORY
PRIMARY
#1
PRIMARY
#2
#1
#2
S
S
000086N
+
+
+
1
2
OFF
BOTH
1
2
OFF
BOTH
ACCESSORY
+
#1
#2
Positive (+) Battery cables
Negative (–) Battery cables
Accessory charge wire, P/N 5006253
50 AMP Fuse
