PAGE 6 BRUNSWICK INSTALLATION MANUAL
BLACK WOLF PRO
FIGURE SIX
FIGURE SIX
Step #14: Square the base frame by measuring the
diagonal corners. Adjust as required.
Step #15: With table in its permanent location, use a
precision level to locate the highest corner of the base
frame. Level the table by adjusting the other three
levelers as required.
BASE FRAME AND LEG ASSEMBLY
(CONTINUED)
