ECLIPSE 8099
INSTRUCTION MANUAL
Section 1 – ORIENTATION (Brunton Eclipse 8099) Page(s): 1 - 3
Section 2 – MAGNETIC DECLINATION 4 - 6
Section 3 – 1° GRADUA
TED DIAL 6
Section 4 – FIELD BEARING (Forward & Reverse Sighting) 6 - 7
Section 5 – DIRECTION OF TRA
VEL
7 - 8
Section 6 – T
OPOGRAPHIC MAP
8
Section 7 – MAP BEARING (Map & Compass Alignment) 8 - 12
Section 8 – TRIANGULATION 12 - 14
Section 9 – BACK BEARING 14
Section 10 – COORDINATE POSITIONING (UTM & Lat./Lon.) 14 - 18
Section 11 – INCLINATION (Hinge, Card & Graduated Dial) 19 - 21
Section 12 – HEIGHT MEASUREMENT (Level & Sloping Ground) 22 - 23
Section 13 – ADDITIONAL INFORMA
TION
23
Section 14 – ECLIPSE 8099 SPECIFICATIONS 23
i
