Bryant 355BAV Plus 95i - ELECTRICAL DATA; BRYANT ACCESSORIES

5
ELECTRICAL DATA
UNIT SIZE 042060 042080 060080 060100 060120
U n i t Vo l t s --- H e r t z --- P h a s e 1 1 5 --- 6 0 --- 1
Operating Voltage Range (Min---Max)* 104---127
Maximum Unit Amps 8.9 8.9 13.8 13.8 13.8
Minimum Wire Size 14 14 12 12 12
Maxium Wire Length (ft){ 31 31 32 32 32
Maximum F use or Ckt Brk (Amps)} 15 15 20 20 20
Transformer (24v) 40va
External Control Power Available Heating 25va
Cooling 34va
* Permissible limits of the voltage range at which the unit will operate satisfactorily.
{ Length shown is as measured 1 way along wire path between unit and service panel for maximum 2% voltage drop.
} Time---delay type is recommended.
BRYANT ACCESSORIES
DESCRIPTION PART NO.
UNIT SIZE
042060 042080 060080 060100 060120
Vent Termination Kit (Bracket Only for 2 Pipes)
2---in. — KGAVT0101BRA
3---in. — KGAVT0201BRA
X X X X X
Concentric Termination Kit (Single Exit)
2---in. — KGAVT0701CVT
3---in. — KGAVT0801CVT
X X X X X
Condensate Freeze Protection Kit KGAHT0101CFP X X X X X
Germicidal Air Purifier Model GAP A X X X X X
Condensate Neutralizer Kit (obtained thru RCD)
P908--- 0001
X X X X X
Electronic Air Cleaner Model EACA X X X X X
Mechanical Air Cleaner
Model FILCAB or
EZXCAB
X X X X X
Humidifier Model HUM X X X X X
Heat Recovery Ventilator Model HRV X X X X X
Energy Recovery Ventilator Model ERV X X X X X
UV Lights Model UVL X X X X X
E Z F l e x M e d i a F i l t e r w i t h e n d c a p s --- 1 6 --- i n . ( 9 p a c k ) EXPXXLMC0016 X
E Z F l e x M e d i a F i l t e r w i t h e n d c a p s --- 2 0 --- i n . ( 9 p a c k ) EXPXXLMC0020 X X X
E Z F l e x M e d i a F i l t e r w i t h e n d c a p s --- 2 4 --- i n . ( 6 p a c k ) EXPXXLMC0024 X
R e p l a c e m e n t E Z F l e x F i l t e r --- 1 6 --- i n . ( 1 0 p a c k ) EXPXXFIL0016 X
R e p l a c e m e n t E Z F l e x F i l t e r --- 2 0 --- i n . ( 1 0 p a c k ) EXPXXFIL0020 X X X
R e p l a c e m e n t E Z F l e x F i l t e r --- 2 4 --- i n . ( 1 0 p a c k ) EXPXXFIL0024 X
E x t e r i o r F i l t e r R a c k --- U n i v e r s a l , 1 --- i n . ( a d j u s t a b l e f r o m 1 4 --- i n . t o
2 4 --- i n . ) w i t h f i l t e r
KGAFR0301ALL
KGAFR0306ALL (6 pack)
X X X X
Unframed Filter 1---in. — 16 x 25
KGAWF1301UFR
KGAWF1306UFR (6 pack)
X S S S
Unframed Filter 1---in. — 20 x 25
KGAWF1401UFR
KGAWF1406UFR (6 pack)
X X X
Unframed Filter 1---in. — 24 x 25
KGAWF1501UFR
KGAWF1506UFR (6 pack)
X
355BAV
