Bryant 581J series User Manual

35
581J*17 COOLING CAPACITIES, SUBCOOLING MODE
581J*17 COOLING CAPACITIES, HOT GAS REHEAT MODE
LEGEND
TEMP (F)
AIR ENT
CONDENSER
(Edb)
AIR ENTERING EVAPORATOR - CFM
4,500 6,000 7,500
Air Entering Evaporator - Ewb (F)
72 67 62 72 67 62 72 67 62
75
TC
202.90 184.60 166.20 213.70 194.60 175.40 222.30 202.50 182.70
SHC
91.90 112.40 132.90 106.10 126.40 146.80 117.50 137.70 158.00
kW
10.19 10.12 9.78 10.51 10.19 9.95 10.61 10.36 10.12
85
TC
189.80 171.80 153.80 201.00 182.20 163.30 209.90 190.40 170.80
SHC
75.90 101.00 126.20 91.20 116.30 141.30 103.40 128.40 153.50
kW
11.57 11.49 11.15 11.88 11.56 11.32 11.98 11.73 11.49
95
TC
176.70 159.10 141.40 188.30 169.70 151.20 197.50 178.20 159.00
SHC
59.80 89.70 119.60 76.20 106.10 135.90 89.40 119.20 149.00
kW
12.87 12.81 12.47 13.20 12.88 12.64 13.30 13.05 12.81
105
TC
163.60 146.30 129.00 175.60 157.30 139.10 185.10 166.10 147.10
SHC
43.80 78.40 112.90 61.30 95.90 130.40 75.30 109.90 144.40
kW
14.05 14.00 13.65 14.39 14.07 13.82 14.40 14.24 14.00
115
TC
150.50 133.50 116.50 162.90 144.90 127.00 172.70 154.00 135.30
SHC
27.70 67.00 106.30 46.40 85.70 125.00 61.30 100.60 133.40
kW
15.44 15.36 15.02 15.75 15.43 15.19 15.85 15.60 15.36
125
TC
137.40 120.80 104.10 150.20 132.50 114.90 160.30 141.90 123.50
SHC
11.70 55.70 99.60 31.40 75.50 112.90 47.30 91.30 123.00
kW
16.77 16.71 16.37 17.10 16.78 16.54 17.20 16.95 16.71
TEMP (F)
AIR ENT
CONDENSER
(Edb)
AIR ENTERING EVAPORATOR - Ewb (F)
75 Dry Bulb
62.5 Wet Bulb
(50% Relative)
75 Dry Bulb
64 Wet Bulb
(56% Relative)
75 Dry Bulb
65.3 Wet Bulb
(60% Relative)
Air Entering Evaporator - Cfm
4,500 6,000 7,500 4,500 6,000 7,500 4,500 6,000 7,500
80
TC
64.50 71.00 73.30 68.40 74.50 77.30 71.20 79.70 80.60
SHC
12.60 24.90 36.80 6.80 13.70 23.90 -0.80 5.50 13.80
kW
10.10 10.26 10.42 10.18 10.40 10.56 10.33 10.47 10.67
75
TC
66.60 73.10 75.60 70.50 76.60 79.50 73.20 80.80 82.90
SHC
14.30 26.70 38.50 8.10 14.90 25.70 0.70 7.00 15.00
kW
10.05 10.22 10.36 10.14 10.36 10.52 10.28 10.43 10.62
70
TC
68.70 75.10 77.40 72.50 78.60 81.40 75.20 82.80 84.90
SHC
15.40 27.80 40.00 9.50 16.20 26.80 2.10 8.40 16.30
kW
10.00 10.18 10.33 10.10 10.31 10.47 10.23 10.40 10.58
60
TC
72.80 79.30 81.60 76.70 82.80 85.70 79.40 86.90 88.80
SHC
19.00 31.10 43.20 12.70 19.90 30.10 5.30 11.60 20.00
kW
9.92 10.09 10.24 10.01 10.22 10.37 10.14 10.31 10.49
50
TC
76.80 83.40 85.70 80.80 86.90 89.70 83.50 90.90 92.80
SHC
21.70 34.20 46.20 15.80 22.70 33.20 8.40 14.70 22.80
kW
9.83 10.00 10.15 9.92 10.13 10.29 10.05 10.21 10.39
40
TC
80.90 87.30 89.60 84.90 90.80 93.60 87.40 94.80 96.70
SHC
24.90 37.10 49.30 19.00 26.00 36.10 11.60 17.90 26.20
kW
9.74 9.91 10.06 9.83 10.04 10.20 9.96 10.12 10.30
Edb — Entering Dry Bulb
Ewb — Entering Wet Bulb
kW — Kilowatts
SHC — Sensible Heat Capacity
TC — Total Capacity
