581J*17-28 WITH TWO-SPEED BLOWER COOLING ELECTRICAL DATA
LEGEND
NOTE: Refer to Packaged Rooftop Builder (Selection Software) for additional
electrical data.
581J
UNIT
SIZE
V-Ph-Hz
VOLTAGE COMP 1 COMP 2 OFM (EA) IFM
COMBUSTION
FAN
MOTOR
POWER
EXHAUST
RANGE
RLA LRA RLA LRA WATTS FLA TYPE
EFFCY
AT FULL
LOAD
FLA FLA
KIT
QTY
FLA
(EA
KIT)
MIN MAX
17
208-3-60 187 253
25.0 164 25.0 164 350 1.5
STD
85.0% 8.6
0.52 2 5.9MED
81.5% 10.8
HIGH
83.6% 13.6
230-3-60 187 253
25.0 164 25.0 164 350 1.5
STD
85.0% 7.8
0.52 2 5.9MED
81.5% 9.8
HIGH
83.6% 12.7
460-3-60 414 506
12.8 100 12.8 100 277 0.9
STD
85.0% 3.8
0.3 2 3.1MED
81.5% 4.9
HIGH
83.6% 6.4
575-3-60 518 633
9.6 78 9.6 78 397 0.6
STD
81.1% 4.5
0.24 2 2.4MED
81.1% 4.5
HIGH
83.6% 6.2
20
208-3-60 187 253
27.6 191 25.0 164 350 1.5
STD
81.5% 10.8
0.52 2 5.9MED
83.6% 13.6
HIGH
89.5% 17.1
230-3-60 187 253
27.6 191 25.0 164 350 1.5
STD
81.5% 9.8
0.52 2 5.9MED
83.6% 12.7
HIGH
89.5% 17.1
460-3-60 414 506
12.8 100 12.2 100 277 0.9
STD
81.5% 4.9
0.3 2 3.1MED
83.6% 6.4
HIGH
89.5% 8.6
575-3-60 518 633
9.6 78 9.0 78 397 0.6
STD
81.1% 4.5
0.24 2 2.4MED
83.6% 6.2
HIGH
89.5% 7.6
24
208-3-60 187 253
28.2 239 28.2 239 350 1.5
STD
83.6% 13.6
0.52 2 5.9MED
89.5% 17.1
HIGH
91.7% 28.5
230-3-60 187 253
28.2 239 28.2 239 350 1.5
STD
83.6% 12.7
0.52 2 5.9MED
89.5% 17.1
HIGH
91.7% 28.5
460-3-60 414 506
14.7 130 14.7 130 277 0.9
STD
83.6% 6.4
0.3 2 3.1MED
89.5% 8.6
HIGH
91.7% 14.3
575-3-60 518 633
11.3 94 11.3 94 397 0.6
STD
83.6% 6.2
0.24 2 2.4MED
89.5% 7.6
HIGH
91.7% 9.5
28
208-3-60 187 253
48.1 245 33.9 240 350 1.5
STD
83.6% 13.6
0.52 2 5.9MED
89.5% 17.1
HIGH
91.7% 28.5
230-3-60 187 253
48.1 245 33.9 240 350 1.5
STD
83.6% 12.7
0.52 2 5.9MED
89.5% 17.1
HIGH
91.7% 28.5
460-3-60 414 506
18.6 125 16.0 140 277 0.9
STD
83.6% 6.4
0.3 2 3.1MED
89.5% 8.6
HIGH
91.7% 14.3
575-3-60 518 633
14.7 100 12.9 108 397 0.6
STD
83.6% 6.2
0.24 2 2.4MED
89.5% 7.6
HIGH
91.7% 9.5
FLA — Full Load Amps
HIGH-HE — High-High Efficiency
IFM — Indoor (Evaporator) Fan Motor
LRA — Locked Rotor Amps
MED-HE — Medium-High Efficiency
OFM — Outdoor Fan Motor
RLA — Rated Load Amps
