LEGEND
LP – Liquid propane
— – Not applicable
PHYSICAL DATA (HEATING - SINGLE PHASE UNITS) 3-5 TONS
582J*04 582J*05 582J*06
ELECTRICAL
Single Phase Single Phase Single Phase
GAS CONNECTION
# of Gas valves 1 1 1
Nat. gas supply line pressure (in. wg) / (PSIG) 4-13 / 0.18-0.47 4-13 / 0.18-0.47 4-13 / 0.18-0.47
LP gas supply line pressure (in. wg) / (PSIG) 11-13 / 0.40-0.47 11-13 / 0.40-0.47 11-13 / 0.40-0.47
HEAT ANTICIPATOR SETTING (AMPS)
First stage 0.14 0.14 0.14
Second stage 0.14 0.14 0.14
NATURAL GAS HEAT
LOW
# of stages / # of burners (total) 1 / 2 1 / 2 1 / 2
Connection size
1
/
2
-in. NPT
1
/
2
-in. NPT
1
/
2
-in. NPT
Rollout switch opens/closes (°F) 195 / 115 195 / 115 195 / 115
Temperature rise (°F) 25-55 20-55 15-55
MED
# of stages / # of burners (total) 1 or 2 / 3 1 / 3 1 / 3
Connection size
1
/
2
-in. NPT
1
/
2
-in. NPT
1
/
2
-in. NPT
Rollout switch opens/closes (°F) 195 / 115 195 / 115 195 / 115
Temperature rise (°F) 45-85 30-65 25-65
HIGH
# of stages / # of burners (total) — 1 or 2 / 3 1 or 2 / 3
Connection size —
1
/
2
-in. NPT
1
/
2
-in. NPT
Rollout switch opens/closes (°F) — 195 / 115 195 / 115
Temperature rise (°F) — 45-80 35-80
LIQUID PROPANE HEAT
LOW
# of stages / # of burners (total) 1 / 2 1 / 2 1 / 2
Connection size
1
/
2
-in. NPT
1
/
2
-in. NPT
1
/
2
-in. NPT
Rollout switch opens/closes (°F) 195 / 115 195 / 115 195 / 115
Temperature rise (°F) 25-55 20-55 15-55
MED
# of stages / # of burners (total) 1 or 2 / 3 1 / 3 1 / 3
Connection Size
1
/
2
-in. NPT
1
/
2
-in. NPT
1
/
2
-in. NPT
Rollout switch opens/closes (°F) 195 / 115 195 / 115 195 / 115
Temperature Rise (°F) 45-85 30-65 25-65
HIGH
# of stages / # of burners (total) — 1 or 2 / 3 1 or 2 / 3
Connection size —
1
/
2
-in. NPT
1
/
2
-in. NPT
Rollout switch opens/closes (°F) — 195 / 115 195 / 115
Temperature rise (°F) — 45-80 35-80
LOW NOX GAS HEAT
LOW
# of stages / # of burners (total) 1 / 2 1 / 2 1 / 2
Connection size
1
/
2
-in. NPT
1
/
2
-in. NPT
1
/
2
-in. NPT
Rollout switch opens/closes (°F) 195 / 115 195 / 115 195 / 115
Temperature rise (°F) 20-50 20-50 15-50
MED
# of stages / # of burners (total) 1 / 3 1 / 3 1 / 3
Connection size
1
/
2
-in. NPT
1
/
2
-in. NPT
1
/
2
-in. NPT
Rollout switch opens/closes (°F) 195 / 115 195 / 115 195 / 115
Temperature rise (°F) 30-60 30-60 25-60
HIGH
# of stages / # of burners (total) — 1 / 3 1 / 3
Connection size —
1
/
2
-in. NPT
1
/
2
-in. NPT
Rollout switch opens/closes (°F) — 195 / 115 195 / 115
Temperature rise (°F) — 40-70 35-70
