DETAILED COOLING CAPACITIES*
See notes on page 25.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
597CN018-F, G Outdoor Section With CK5A/CK5B018 Indoor Section
525
72 19.5 9.60 1.40 18.8 9.33 1.58 18.0 9.05 1.77 17.2 8.75 1.98 16.3 8.44 2.21
67 17.8 12.1 1.38 17.1 11.9 1.55 16.4 11.6 1.74 15.6 11.2 1.95 14.8 10.9 2.17
62 16.2 14.6 1.37 15.6 14.3 1.54 14.9 14.0 1.72 14.3 13.6 1.93 13.5 13.2 2.16
57 15.6 15.6 1.36 15.1 15.1 1.54 14.5 14.5 1.73 14.0 14.0 1.93 13.4 13.4 2.16
600
72 19.8 10.0 1.44 19.1 9.74 1.61 18.3 9.45 1.80 17.4 9.16 2.01 16.5 8.84 2.25
67 18.1 12.8 1.41 17.4 12.6 1.58 16.7 12.3 1.77 15.9 11.9 1.98 15.0 11.6 2.21
62 16.6 15.5 1.40 15.9 15.2 1.57 15.2 14.8 1.76 14.6 14.4 1.97 13.8 13.8 2.20
57 16.1 16.1 1.39 15.6 15.6 1.56 15.0 15.0 1.75 14.5 14.5 1.96 13.8 13.8 2.19
675
72 20.0 10.4 1.46 19.2 10.1 1.63 18.4 9.81 1.82 17.6 9.51 2.03 16.7 9.19 2.26
67 18.3 13.5 1.44 17.6 13.2 1.61 16.9 12.9 1.80 16.1 12.6 2.01 15.2 12.3 2.24
62 16.8 16.4 1.43 16.2 16.0 1.60 15.5 15.5 1.79 14.9 14.9 2.00 14.2 14.2 2.23
57 16.6 16.6 1.43 16.0 16.0 1.59 15.5 15.5 1.78 14.8 14.8 1.99 14.2 14.2 2.22
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 018 1.00 1.00
COILS + 315(A,J)AV036070 VARIABLE SPEED FURNACE
024 1.02 1.00 CC5A/CD5AA 018 0.97 0.89
CC5A/CD5AW 024 1.02 1.00 024 1.00 0.89
CE3AA 024 1.01 1.00 CC5A/CD5AW 024 1.00 0.89
CK3BA 024 1.02 1.00 CE3AA 024 0.99 0.88
CK5A/CK5BA 018 1.00 1.00 CK3BA 024 1.00 0.88
024 1.02 1.00 CK5A/CK5BA 018 0.98 0.88
CK5A/CK5BW 024 1.02 1.00 024 1.00 0.88
F(A,B)4(A,B)N(F,C) 018 0.98 0.98 CK5A/CK5BW 024 1.00 0.88
024 1.01 0.99
COILS + 355MAV042060 VARIABLE SPEED FURNACE
FC4(B,C)NF 024 1.01 0.99 CC5A/CD5AW 024 1.01 0.93
FF1DNA 018 0.98 0.96 CK5A/CK5BW 024 1.01 0.93
024 1.01 1.00
COILS + 355MAV042080 VARIABLE SPEED FURNACE
FG3AAA 024 1.00 1.00 CC5A/CD5AW 024 1.01 0.92
FK4(C,D)NF 001 1.03 0.91 CK5A/CK5BW 024 1.01 0.92
002 1.03 0.91 —— —
