—17—
DETAILED COOLING CAPACITIES* Continued
See notes on page 25.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
597CN024-F, G Outdoor Section With CC5A/CD5AA024 Indoor Section
700
72 25.7 12.6 1.88 24.8 12.3 2.09 23.8 11.9 2.31 22.7 11.5 2.5 21.6 11.1 2.84
67 23.4 15.9 1.89 22.6 15.5 2.09 21.6 15.1 2.31 20.7 14.7 2.5 19.7 14.3 2.82
62 21.3 19.1 1.89 20.5 18.7
2.09 19.6 18.2 2.30 18.7 17.8 2.5 17.8 17.3 2.82
57 20.3 20.3 1.89 19.6 19.6 2.09 18.9 18.9 2.30 18.2 18.2 2.5 17.5 17.5 2.82
800
72 26.1 13.2 1.92 25.2 12.8 2.13 24.2 12.5 2.35 23.1 12.1 2.6 22.0 11.7 2.88
67 23.9 16.8 1.92 23.0 16.5 2.13 22.0 16.1 2.35 21.0 15.7 2.6 20.0 15.3 2.86
62 21.8 20.3 1.93 20.9 19.9 2.13 20.0 19.4 2.34 19.1 18.8 2.5 18.2 18.2 2.86
57 21.1 21.1 1.93 20.4 20.4 2.12 19.7 19.7 2.34 18.9 18.9 2.5 18.1 18.1 2.87
900
72 26.5 13.7 1.96 25.6 13.3 2.17 24.5 13.0 2.39 23.4 12.6 2.6 22.2 12.2 2.92
67 24.2 17.7 1.96 23.3 17.4 2.17 22.3 17.0 2.39 21.3 16.6 2.6 20.2 16.2 2.90
62 22.1 21.4 1.97 21.3 20.9 2.17 20.4 20.3 2.38 19.5 19.5 2.6 18.7 18.7 2.91
57 21.8 21.8 1.96 21.1 21.1 2.16 20.3 20.3 2.38 19.5 19.5 2.6 18.7 18.7 2.90
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 024 1.00 1.00 CE3AA 024 1.00 0.91
030 1.01 1.00 030 1.01 0.90
CC5A/CD5AW 024 1.00 1.00 CK3BA 024 1.00 0.90
030 1.01 1.00 030 1.01 0.90
CE3AA 024 1.00 1.00 CK5A/CK5BA 024 1.00 0.90
030 1.01 1.00 030 1.01 0.90
CF5AA 024 1.00 1.00 CK5A/CK5BW 024 1.00 0.90
CK3BA 024 1.00 1.00 030 1.01 0.90
030 1.01 1.00
COILS + 355MAV042040 VARIABLE SPEED FURNACE
CK5A/CK5BA 024 1.00 1.00 CC5A/CD5AA 024 1.01 0.93
030 1.01 1.00 030 1.03 0.92
CK5A/CK5BW 024 1.00 1.00 CK3BA 024 1.00 0.94
030 1.01 1.00 030 1.01 0.93
F(A,B)4(A,B)NF 024 1.01 1.00 CK5A/CK5BW 030 1.01 0.93
030 1.03 0.99
COILS + 355MAV042060 VARIABLE SPEED FURNACE
FC4(B,C)NF 024 1.01 1.00 CC5A/CD5AA 024 1.01 0.93
030 1.03 0.99 030 1.03 0.92
FF1DNA 024 1.00 1.01 CK3BA 024 1.00 0.94
030 1.03 1.01 030 1.01 0.94
FG3AAA 024 0.99 1.00 CK5A/CK5BW 024 1.00 0.94
FK4(C,D)NF 001 1.02 0.93 030 1.01 0.94
002 1.03 0.93
COILS + 355MAV042080 VARIABLE SPEED FURNACE
003 1.03 0.90 CC5A/CD5AA 024 1.01 0.93
004 1.04 0.91 030 1.03 0.92
COILS + 315(A,J)AV036070 VARIABLE SPEED FURNACE CK3BA 024 1.00 0.92
CC5A/CD5AA 024 1.00 0.91 030 1.01 0.92
030 1.01 0.91 CK5A/CK5BW 024 1.00 0.92
CC5A/CD5AW 024 1.00 0.91 030 1.01 0.92
030 1.01 0.91 —— —
